Access point Aruba (HPE) S1G84A
3188 $
HPE ANW AP-755 (RW) Campus AP.
Access points Aruba (HPE) provide fast and stable wireless data transmission in the corporate network. Aruba offers both simple devices for providing basic Wi-Fi network functionality and for networks with high user density and speeds up to 2 GbIT/s, and also protected models for operation in difficult climatic conditions.
Access points are simple in installation, can work simultaneously in ranges 2,4 and 5 GHz, They use technology MIMO To increase the data rate and support the standard 802.11ac Wave2.
Instant-Access points Aruba — do not require a separate controller, but use a virtual controller whose functions performed one of the points. HPE Aruba Instant — This is a solution that allows you to deploy an "uncontrolled" WiFi level network. He already has built -in network safety, automatic control RF and enough intellectual functions to start a full solution without additional licensing. Controls cluster from access points using a virtual controller that is placed at one of the access points (IAP). The controller is responsible for the process of auto configuration of new access points, authorization and authentication, guest access and network services (NAT, DHCP and others.).
Specifications Access points Aruba (HPE) S1G84A:
| Specification Category | Details |
|---|---|
| Product Name / Model | HPE Aruba AP-755 (S1G84A) |
| Device Type | Indoor, tri-radio, 4×4 MIMO, Wi-Fi 7 (802.11be), internal downtilt omni antennas |
| Wireless Radios / Bands | Concurrent 2.4 GHz, 5 GHz, and 6 GHz (802.11be) |
| Throughput per Radio (SU-MIMO) | • 2.4 GHz: up to 1.4 Gbps (4-stream EHT40) • 5 GHz: up to 5.8 Gbps (2-stream EHT160) • 6 GHz: up to 11.5 Gbps (2-stream EHT320) |
| Aggregate Data Rate | Up to 18.7 Gbps across tri-band; up to 28.8 Gbps in dual-radio mode (5 GHz + 6 GHz) |
| Client & BSSID Capacity | Up to 512 clients and 16 BSSIDs per radio |
| Ultra Tri-Band (UTB) Filtering | Enables 5 GHz and 6 GHz to operate without coverage gaps or interference |
| Ethernet Interfaces | Two RJ-45 Smart Rate ports (auto-sensing 100/1G/2.5G/5G/10GBASE-T); support link aggregation and redundancy |
| PoE / Power Options | Supports 802.3af/at/bt PoE (class 3+), or 12 VDC input; DC takes priority |
| USB & IoT Support | Two USB 2.0 hosts (Type-A), up to 2 A/10 W; integrated Bluetooth 5.4 + 802.15.4 (Zigbee) IoT radios |
| Location / Sensors | Built-in GNSS receiver (GPS, Galileo, GLONASS, BeiDou), barometric pressure sensor (indoor self-location) |
| Security Features | TPM, MACsec on E0, WPA3, Enhanced Open, Dynamic Segmentation, policy enforcement firewall (PEF) |
| Power Consumption | DC: up to 35 W (up to 46 W w/USB); PoE: up to 40 W (up to 51 W w/USB). Idle: 14–25 W; Deep sleep: 2.4–3.5 W |
| Dimensions & Weight | Unit: 260×260×57 mm, 1 530 g; Shipping: 350×320×83 mm, 2 130 g |
| Operating Environment | Temp: 0 °C to +50 °C; RH: 5 – 95%; Plenum-rated (ETS 300 019 class 3.2) |
| Other Features | LEDs for system and radio status, reset button, micro-USB console, Kensington slot, thermal shutdown protection |
| condition | new |
|---|
