Access point Aruba (HPE) S5Q98A
Indoor access point, tri-radio, Wi-Fi 7 (802.11be), 4×4 + 2×2 MIMO, internal antennas
Access points Aruba (HPE) provide fast and stable wireless data transmission in the corporate network. Aruba offers both simple devices for providing basic Wi-Fi network functionality and for networks with high user density and speeds up to 2 GbIT/s, and also protected models for operation in difficult climatic conditions.
Access points are simple in installation, can work simultaneously in ranges 2,4 and 5 GHz, They use technology MIMO To increase the data rate and support the standard 802.11ac Wave2.
Instant-Access points Aruba — do not require a separate controller, but use a virtual controller whose functions performed one of the points. HPE Aruba Instant — This is a solution that allows you to deploy an "uncontrolled" WiFi level network. He already has built -in network safety, automatic control RF and enough intellectual functions to start a full solution without additional licensing. Controls cluster from access points using a virtual controller that is placed at one of the access points (IAP). The controller is responsible for the process of auto configuration of new access points, authorization and authentication, guest access and network services (NAT, DHCP and others.).
Specifications Access points Aruba (HPE) S5Q98A:
| Specification Category | Details |
|---|---|
| Product Name / Model | Aruba HPE AP-745 (S5Q98A) |
| Device Type | Indoor access point, tri-radio, Wi-Fi 7 (802.11be), 4×4 + 2×2 MIMO, internal antennas |
| Wireless Radios / Configuration | Tri-radio: 4×4 MIMO + 2×2 MIMO (likely combination across bands) |
| Wireless Standard | Wi-Fi 7 (802.11be) |
| Aggregate Data Rate | Up to 28.8 Gbps combined peak throughput (same family as 750 series) |
| Ethernet Interface | Typically includes at least 5 Gbps wired uplink (standard for 740/750 series) |
| IoT & USB Extensions | Integrated IoT radio (Bluetooth + Zigbee); possible USB ports for IoT / local device integration |
| Location & Sensors | Internal sensors may include GNSS and barometric for indoor location services |
| Ultra Tri-Band (UTB) Filtering | UTB filtering to enable seamless, interference-minimized operation across 5 GHz and 6 GHz |
| Management Platform | Aruba OS-10; managed via Aruba Central with AI-powered insights and automation |
| Target Use Cases | Enterprise environments requiring high throughput, low latency, dense client support, IoT integration |
| Security Features | TPM, WPA3, Enhanced Open, Dynamic Segmentation, Policy Enforcement Firewall |
| Operating Software Version | Requires minimum Aruba OS-10.8 |
| Warranty / Lifecycle Status | Active lifecycle product; standard Aruba warranty applies |
| condition | new |
|---|
