Software
|
- Cisco Unified Wireless Network Software Release 8.10.MR3 or later
- Cisco IOS XE Software Release 17.3.1, or later
|
Supported wireless LAN controllers
|
- Cisco Catalyst 9800 Series Wireless Controllers
- Cisco 3504, 5520, and 8540 Wireless Controllers and Cisco Virtual Wireless Controller
|
802.11n version 2.0 (and related) capabilities
|
- 2x2 MIMO with two spatial streams
- Maximal Ratio Combining (MRC)
- 802.11n and 802.11a/g
- 20- and 40-MHz channels
- PHY data rates up to 444.4 Mbps (40 MHz with 5 GHz and 20 MHz with 2.4 GHz)
- Packet aggregation: Aggregate MAC Protocol Data Unit (A-MPDU) (transmit and receive), Aggregate MAC Service Data Unit (A-MSDU) (transmit and receive)
- 802.11 Dynamic Frequency Selection (DFS)
- Cyclic Shift Diversity (CSD) support
|
802.11ac
|
- 2x2 downlink MU-MIMO with two spatial streams
- MRC
- 802.11ac beamforming
- 20-, 40-, 80- MHz channels
- PHY data rates up to 866.7 Mbps (80 MHz with 5GHz)
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- WPA3 support
|
802.11ax
|
- 2x2 uplink/downlink MU-MIMO with two spatial streams
- Uplink/downlink OFDMA
- TWT
- BSS coloring
- MRC
- 802.11ax beamforming
- 20-, 40-, 80- channels
- PHY data rates up to 1.488 Gbps (80 MHz with 5 GHz and 20 MHz with 2.4 GHz)
- Packet aggregation: A-MPDU (transmit and receive), A-MSDU (transmit and receive)
- 802.11 DFS
- CSD support
- WPA3 support
|
Integrated antenna
|
- 2.4 GHz: Peak gain 4 dBi, internal antenna, omnidirectional in azimuth
- 5 GHz: Peak gain 5 dBi, internal antenna, omnidirectional in azimuth
|
Interfaces
|
- 1x 10/100/1000 Base-T (Ethernet) Uplink Interface
- Management console port (RJ-45)
|
Indicators
|
Status LED indicates boot loader status, association status, operating status, boot loader warnings, and boot loader errors
|
Dimensions (W x L x H)
|
5.9 x 5.9 x 1.18 in. (150 x 150 x 30 mm)
|
Weight
|
0.7 lb. (329.5g)
|
Input power requirements
|
- 802.3at Power over Ethernet Plus (PoE+), Cisco Universal PoE (Cisco UPOE ®)
- Cisco power injector, AIR-PWRINJ6=
- 802.3af PoE
- Cisco power injector, AIR-PWRINJ5=
|
PoE power
|
802.3af (PoE)
|
Link speed
|
1G
|
Environmental
|
- Nonoperating (storage) temperature: -22° to 158°F (-30° to 70°C)
- Nonoperating (storage) altitude test: 25˚C, 15,000 ft (4600 m)
- Operating temperature: 32° to 122°F (0° to 50°C)
- Operating humidity: 10% to 90% (noncondensing)
- Operating altitude test: 40˚C, 9843 ft.(3000 m)
|
Available transmit power settings (Max/Min)
|
- 2.4 GHz: 20 dBm (100 mW), -7 dBm (0.2 mW)
- 5 GHz: 20 dBm (100 mW), -7 dBm (0.2 mW)
|
