Access point Cisco CW9163E-E
Catalyst 9163 Series (outdoor Wi‑Fi 6E, 802.11ax) One 1×1 tri-band (2.4/5/6 GHz) for CleanAir Pro, WIPS, spectrum analysis
Cisco Catalyst 9100 – An innovative series of access to the Internet of the Corporate Plan, which are equipped with a state -of -the -art hardware part and support modern patented Technologies and techniques Cisco.
The units of this level are profiled on modern high -tech firms and businesses that value high level of productivity and safety.
The line of new access points Cisco Catalyst 9100 represented by several subseries, both for external and internal location of access points. The features of series can be attributed - Wi-Fi 6-th generation or 802.11ax, which provides triple increase in Internet signal reception and transmission speed, simultaneous operation on all frequencies, interface for connecting to a multigigabit network, new power-saving mode extends battery life, trust technology support ensuring software and hardware authenticity, Wi-Fi 6 certification, three radio modules: 2,4 GHz, 5 GHz and low energy Bluetooth (BLE) 5,0, support OFDMA and MU-MIMO 4x4
Specifications of access point Cisco CW9163E-E:
| Specification | Details |
|---|---|
| Model | CW9163E‑E |
| Product Family | Catalyst 9163 Series (outdoor Wi‑Fi 6E, 802.11ax) |
| Release Date | November 15, 2023 |
| Management Options | On-premises (Catalyst 9800 controllers) or cloud-managed (Cisco Meraki) |
| Client Radios | Three 2×2 MU‑MIMO: 2.4 GHz, 5 GHz, 6 GHz |
| Scanning Radio | One 1×1 tri-band (2.4/5/6 GHz) for CleanAir Pro, WIPS, spectrum analysis |
| IoT/BLE Radio | Single‑stream 2.4 GHz BLE for IoT, location services |
| Tri‑radio Aggregate Rate | Up to 3.9 Gbps |
| Concurrent Radios | All five radios operating simultaneously |
| Beamforming & MIMO | 2×2 UL/DL MU‑MIMO, OFDMA, 1024‑QAM, TWT, BSS coloring, beamforming |
| CleanAir Pro | Yes — enhanced RF interference detection across all bands |
| Antenna Ports | 4 × external N‑type connectors; supports Self‑Identifying Antennas |
| Built‑in GPS/GNSS | Yes, for AFC compliance; external GNSS port included |
| Ethernet Port | 1 × Multigigabit RJ‑45 (100 M/1G/2.5G) PoE‑IN |
| Power Standards | 802.3at PoE+/802.3af (degraded mode); supports Cisco/Meraki injectors (AIR‑PWRINJ6/7, MA‑INJ‑4/6) |
| Physical Dimensions | 9.64″ × 9.64″ × 2.5″ (245 × 245 × 63.5 mm) |
| Weight | 3.3 lb (1.5 kg) |
| Environmental Rating | IP67; wind resistance up to 100/165 mph (sustained/gust) |
| Temperature Range | –40 °C to +65 °C |
| Security & Encryption | WPA3/WPA2‑Enterprise, AES, 802.1X, Secure Boot, Trust Anchor |
| Bluetooth Standard | BLE 5.1 |
| Software Requirements | IOS XE 17.12.3+ (on-premises); Meraki platform for cloud management |
| Licensing | Cisco DNA subscription (Essentials/Advantage) or Meraki license (if cloud-managed) |
| Part Number(s) | CW9163E‑E (regulatory region E) |
| Accessories | External antennas (CW‑ANT‑O1, D1); GPS antenna (CW‑ANT‑GPS2‑00); PoE injectors, mounting kits |
| Warranty | Standard Cisco limited lifetime hardware warranty |
| condition | new |
|---|
