Firewall Huawei USG6565F-АС
USG6565F AC host (2*GE RJ45 + 8*GE COMBO + 2*10GE SFP+, 1 AC power)
- Multi-level protection: USG6500 provides multi-layered protection against various threats, including malware, attacks DDoS, Internal threats and more.
- Intelligent attack detection and prevention (IDP/IPS): Offers intelligent attack detection and prevention features using signature and anomaly traffic analysis.
- VPN (Virtual private network): USG6500 supports various VPN protocols, such as IPsec, SSL VPN and L2TP, providing a secure remote connection to the network.
- Access control and security policies: Allows you to configure flexible access rules and security policies to control network traffic, including filtering URL-addresses, application control and much more.
- Protection against malware and viruses: Has built-in antivirus and antispam features to detect and block malware and spam.
- Load balancing and fault tolerance: Supports load balancing between multiple communication channels and provides fault tolerance using redundancy and routing mechanisms.
- Convenient management and monitoring: Offers easy-to-use network management and monitoring tools, including a web interface, console management, and centralized management via management protocols.
- High performance and scalability: Firewalls Huawei USG6500 have high performance and scalability, allowing you to handle large volumes of traffic and meet the needs of different types enterprise networks.
Technical specifications of the firewall Huawei USG6565F-AS:
|
Model |
USG6565F |
|
Hardware Specifications |
|
|
Dimensions (W x D x H) mm |
• 442 × 420 × 43.6 |
|
Form Factor/Height |
• 1 U |
|
Fixed Interface |
• 2*GE RJ45 + 8*GE COMBO + 2*10GE SFP+ |
|
USB Port |
• 2 x USB 2.0 |
|
Weight |
• 5.46 kg |
|
External Storage |
• Optional, M.2 SSD (64 GB/240 GB), hot-swappable |
|
Power Supply |
• 100 V to 240 V, 50 Hz/60 Hz |
|
Maximum power consumption of the machine |
• 49.5 W |
|
Power Supplies |
• Optional dual power modules for 1+1 redundancy |
|
Operating Environment (Temperature/Humidity) |
• Temperature: 0°C to 45°C • Humidity: 5% to 95%, non-condensing |
|
Non-operating Environment |
• Temperature: –40°C to +70°C • Humidity: 5% to 95%, non-condensing |
|
System Performance and Capacity |
|
|
IPv4 Firewall Throughput (1518/512/64-byte, UDP) |
• 7/7/3.6 Gbps |
|
IPv6 Firewall Throughput (1518/512/84-byte, UDP) |
• 7/7/3.6 Gbps |
|
Firewall Throughput (Packets Per Second) |
• 5.4 Mpps |
|
Firewall Latency (64-byte, UDP) |
• 18 us |
|
FW + SA* Throughput2 |
• 3 Gbps |
|
NGFW Throughput (HTTP 100K) |
• 2.2 Gbps |
|
NGFW Throughput (Enterprise Mix) |
• 1.2 Gbps |
|
Threat Protection Throughput (HTTP 100K) |
• 2 Gbps |
|
Threat Protection Throughput (Enterprise Mix) |
• 1.1 Gbps |
|
Concurrent Sessions |
• 4000000 |
|
IPv6 Concurrent Sessions |
• 3000000 |
|
New Sessions/Second (HTTP1.1) |
• 80000 |
|
IPv6 New Sessions/Second (HTTP1.1) |
• 80000 |
|
IPsec VPN Throughput1 (AES-256 + SHA256, 1420-byte) |
• 3.7 Gbps |
|
Maximum IPSec VPN Tunnels (GW to GW) |
• 4000 |
|
Maximum IPsec VPN Tunnels (Client to GW) |
• 4000 |
|
SSL Inspection Throughput |
• 500 Mbps |
|
SSL VPN Throughput |
• 500 Mbps |
|
Concurrent SSL VPN Users (Default/Maximum) |
• 100/2,000 |
|
Security Policies (Maximum) |
• 15000 |
|
Virtual Firewalls |
• 100 |
|
URL Filtering: Categories |
• More than 130 |
|
URL Filtering: URLs |
• A database of over 500 million URLs in the cloud |
|
Automated IPS Signature Updates |
• Yes, an industry-leading security center from Huawei |
|
Third-Party and Open-Source Ecosystem |
• Open API for integration with third-party products, providing NETCONF interfaces • Other third-party management software based on SNMP, SSH, and Syslog |
|
VLANs (Maximum) |
• 4094 |
|
VLANIF Interfaces (Maximum) |
• 4094 |
