Module Cisco C9400-LC-12QC
SKU
C9400-LC-12QC
EAN:
20037
Condition:
new
Stock:
available on order
Lead time:
25-35 days
12 × 40 GbE QSFP+ or 4 × 100 GbE QSFP28 + 4 × 40 GbE QSFP+ simultaneously supported
Category: Line Cards
Unique capabilities of a series of switches Cisco Catalyst 9400 provide high protection of your organization before, during and after attack by reliable systems Cisco and encryption MACSEC256.
Switches Cisco 9400 series ensure the use of the Internet of things with a leading industry level. They also provide up to 384 ports up to 60W for UPOE, as well as POE+ and POE, high security, AVB support and IEEE 1588...
Catalyst 9400 Provides high accessibility based on partial updates using technology GIR for safe installation and removal of software and equipment.
Specifications Cisco C9400-LC-12QC:
| Specification | Cisco C9400‑LC‑12QC |
|---|---|
| Module Type | Fiber line card for Cisco Catalyst 9400 Series modular switch |
| Port Configuration | • 12 × 40 GbE QSFP+ or 4 × 100 GbE QSFP28 + 4 × 40 GbE QSFP+ simultaneously supported (cisco.com) |
| Optics Support | Standard QSFP28 (100 GbE) and QSFP+ (40 GbE) optics; simultaneous mix allowed |
| Slot Bandwidth | • With SUP‑2XL: 480 Gbps per slot, 1:1 oversubscription • With SUP‑2: 240 Gbps per slot, 2:1 oversubscription (cisco.com) |
| Jumbo Frame Support | Up to 9,216 bytes (Layer 2–4) |
| MACsec Encryption | Hardware-based IEEE 802.1AE MACsec‑256 at line rate |
| Chassis & Supervisor Compatibility | Requires Catalyst 9400 chassis with SUP‑2 or SUP‑2XL only; IOS XE 17.12.1+ |
| Energy Efficiency | Supports Energy Efficient Ethernet (802.3az) |
| Operating Temperature | 0 °C to +45 °C (32 °F to 113 °F) |
| Physical Dimensions | 1.6″ × 14.9″ × 14.6″ (H × W × D) / ~4.06 × 37.9 × 37.0 cm |
| condition | new |
|---|
