Module Cisco C9400-LC-24XY
SKU
C9400-LC-24XY
EAN:
20036
Condition:
new
Stock:
available on order
Lead time:
25-35 days
20 × 25 GbE (SFP28) ports (dual-rate 1/10/25 GbE)– 4 × 10 GbE (SFP+) ports
Category: Line Cards
Unique opportunities Cisco Catalyst 9400 provide high protection of your organization before, during and after attack by reliable systems Cisco and encryption MACSEC256.
Cisco 9400 series ensure the use of the Internet of things with a leading industry level. They also provide up to 384 ports up to 60W for UPOE, as well as POE+ and POE, high security, AVB support and IEEE 1588...
Catalyst 9400 Provides high accessibility based on partial updates using technology GIR for safe installation and removal of software and equipment.
Specifications module Cisco C9400-LC-24XY:
| Specification | Cisco C9400‑LC‑24XY |
|---|---|
| Module Type | Fixed line card for Cisco Catalyst 9400 Series |
| Port Configuration | – 20 × 25 GbE (SFP28) ports (dual-rate 1/10/25 GbE)– 4 × 10 GbE (SFP+) ports (cisco.com) |
| Uplink Capability | Supports 4-port uplinks using SFP+ or SFP28; dual-rate up to 25 GbE |
| Bandwidth per Slot | Non-blocking 6.4 Tbps across the slot |
| Chassis Compatibility | Works with Catalyst 9400 chassis and SUP-1XL-Y, SUP-2/2XL supervisors; requires IOS XE 17.12.1+ |
| MACsec Encryption | Hardware-based IEEE 802.1AE (MACsec‑256) encryption at line rate |
| Jumbo Frames Support | Up to 9216-byte frame size |
| Temperature Range | Operating: –5 °C to +45 °C (23 °F to 113 °F) |
| Dimensions | 1.6″ × 14.9″ × 14.6″ (H × W × D) (4.06 × 37.9 × 37.0 cm) |
| Typical Use Cases | High-density aggregation/core in enterprise campuses or data centers; mixed 25 / 10 GbE access with uplinks |
| condition | new |
|---|
