Interface or line modules Aruba HPE enable specialists to control the status and loading of all infrastructure components without exception (access points, controllers, switches) and choose the configuration of existing as well as put into operation new hardware devices.
The AirWave option allows you to receive information about network-integrated users, collect statistics about their actions and traffic.
Features of interface modules Aruba HPE:
- turning an array of switches into one large virtual device, where each node of the stack has a common IP address (stacking);
- backup cooling, which is installed in hot-swappable mode and is activated in case of failure of the main (used) fans;
- connecting more network devices through interfaces not available on the switch by default (For example, SFP+ or CX4).
Interface or line modules Aruba HPE (line card, interface module) make it possible to expand the router or modular platform with the required functionality, including the necessary access ports at different speeds. Control or Processor modules (Routing Engine, Supervisor) Aruba HPE used in routers or modular switches to control the entire system and increase its performance.
Specifications of the interface module HPE FlexFabric R9F19A:
|
Ports
|
16 I/O module slots, maximum
Supports a maximum of 768 40GbE, 768 10GbE, 1/10GbE copper, 1/10GbE fiber, 1GbE fiber, or 10/100/1000 ports, or 576 100GbE ports, or a combination
|
|
Throughput
|
92.1 Bpps
Maximum, depending on model and configuration
|
|
Switching capacity
|
184 Tbps
Maximum, depending on model and configuration
|
|
Stacking capabilities
|
IRF
2 switches
|
|
Management features
|
IMC - Intelligent Management Center
Command-line interface
Out-of-band management (serial RS-232C)
SNMP manager
Telnet
Terminal interface (serial RS-232C)
Modem interface
IEEE 802.3 Ethernet MIB
Ethernet interface MIB
|
|
Input voltage
|
-48 to -60 VDC, depending on model and configuration
|
|
Product Dimensions (imperial)
|
2 x 17.1 x 20.5 in
|
|
Weight
|
22.3 lb
|
