Nvidia BlueField-2 Ethernet DPU 900-9D206-0053-SQ0
NVIDIA BlueField-2 DPU, model 900-9D206-0053-SQ0, features dual 25GbE SFP28 Ethernet ports, PCIe Gen4 x8 host interface, 8 ARMv8 A72 cores, 16GB DDR4 memory, and hardware acceleration for networking, security, and storage. It supports SR-IOV, VirtIO, IPsec, TLS, NVMe-oF, and RoCE v2, with advanced offloads and programmable pipeline capabilities.
NVIDIA BlueField-2 - This is a specialized network processor (DPU), which integrates the functions of a switch, system controller, and hardware accelerator. The device is based on the architecture with multi-core Armv8-A processors and is equipped with network adapters NVIDIA ConnectX-6 Dx with Ethernet or Infiniband support at speed up to 200 GbIT/with. intended to offload the central processor by performing infrastructure tasks at the hardware level.
BlueField-2 Supports isolation of key functions - including encryption, firewalls, routing, storage management and network resource virtualization.
Built -in security mechanisms correspond to the Zero Trust concept that prevents unauthorized access. Hardware acceleration can significantly reduce data delays and increase overall bandwidth while reducing power consumption.
Software ecosystem NVIDIA DOCA Provides compatibility with modern development tools and allows us to create user services to manage network, security and storage. Supports virtualization, containerization and adaptation to cloud environments.
BlueField-2 Applied in Date Centers, Artificial Intelligence Systems, Cloud Infrastructures and Telecommunication Equipment. The device provides stable operation under high loads and important calculations, supporting stable operation of services 24/7.
The architecture of the device is scaled, allowing it to be used as part of individual servers, and in complex distributed infrastructures. High density of function integration makes Bluefield-2 a universal solution to build reliable and safe computing environments.
Specifications Nvidia BlueField-2 Ethernet DPU 900-9D206-0053-SQ0:
| Parameter | Specification |
|---|---|
| Model Number | 900-9D206-0053-SQ0 |
| Product Family | NVIDIA BlueField-2 DPU |
| Network Interface | Dual 25GbE SFP28 |
| Host Interface | PCIe Gen4 x8 |
| Processor | 8-core ARMv8 A72 |
| Memory | 16GB DDR4 |
| Storage | eMMC, microSD (optional for boot/debug) |
| Acceleration Engines | Hardware acceleration for networking, security, storage |
| Security Features | IPsec, TLS, AES, SHA, Secure Boot, Crypto acceleration |
| Virtualization Support | SR-IOV, VirtIO, Containers, VMs |
| Remote Management | BMC, Redfish, PLDM |
| NVMe-oF Support | Yes |
| RoCE Support | RoCE v2 |
| Firmware Upgrade | Secure firmware upgrade supported |
| Power Consumption | ~25W (typical) |
| Form Factor | PCIe Low-profile |
| Compliance | PCIe Gen4, RoHS, CE, FCC |
| condition | new |
|---|
