Nvidia BlueField-2 Ethernet DPU 900-9D206-0063-ST2
NVIDIA BlueField-2 Ethernet DPU model 900-9D206-0063-ST2 is a Half-Height Half-Length (HHHL) PCIe Gen4 x8 card, equipped with dual 25GbE SFP56 ports and powered by the BlueField-2 SoC with an 8-core Arm Cortex-A72 processor operating at 2.5GHz.
NVIDIA BlueField-2 - This is a specialized network processor (DPU), which integrates the functions of a switch, system controller, and hardware accelerator. The device is based on the architecture with multi-core Armv8-A processors and is equipped with network adapters NVIDIA ConnectX-6 Dx with Ethernet or Infiniband support at speed up to 200 GbIT/with. intended to offload the central processor by performing infrastructure tasks at the hardware level.
BlueField-2 Supports isolation of key functions - including encryption, firewalls, routing, storage management and network resource virtualization.
Built -in security mechanisms correspond to the Zero Trust concept that prevents unauthorized access. Hardware acceleration can significantly reduce data delays and increase overall bandwidth while reducing power consumption.
Software ecosystem NVIDIA DOCA Provides compatibility with modern development tools and allows us to create user services to manage network, security and storage. Supports virtualization, containerization and adaptation to cloud environments.
BlueField-2 Applied in Date Centers, Artificial Intelligence Systems, Cloud Infrastructures and Telecommunication Equipment. The device provides stable operation under high loads and important calculations, supporting stable operation of services 24/7.
The architecture of the device is scaled, allowing it to be used as part of individual servers, and in complex distributed infrastructures. High density of function integration makes Bluefield-2 a universal solution to build reliable and safe computing environments.
Specifications Nvidia BlueField-2 Ethernet DPU 900-9D206-0063-ST2:
| Specification | Details |
|---|---|
| SoC Model | BlueField-2 P-Series, 8 cores operating at 2.5 GHz |
| Form Factor | Half-Height Half-Length (HHHL) |
| Dimensions | Card: 68.90 mm x 167.65 mm<br>Bracket: 121.0 mm x 21.6 mm |
| Network Interface | 2 x SFP56 ports supporting 25 GbE |
| PCIe Interface | PCI Express Gen 4.0 x8 (compatible with Gen 3.0, 2.0, and 1.1) |
| On-board Memory | 16 GB DDR4 with ECC<br>64 GB eMMC memory |
| Security Features | Crypto Enabled<br>Secure Boot Disabled |
| Out-of-Band Management | 1 GbE OOB |
| Power Supply | 12V |
| Environmental Conditions | Operational Temperature: 0°C to 55°C<br>Operational Humidity: 10% to 85% relative humidity |
| Regulatory Compliance | Safety: CB / cTUVus / CE<br>EMC: CE / FCC / VCCI / ICES / RCM<br>RoHS compliant |
| condition | new |
|---|
