Nvidia BlueField-2 Ethernet DPU 900-9D208-0076-ST6
The NVIDIA BlueField-2 DPU model 900-9D208-0076-ST6 is equipped with dual 25GbE SFP28 ports and offers a PCIe Gen4 x16 interface. It integrates a 16-core ARM Cortex-A72 processor (two 8-core clusters) along with 16GB of DDR4 ECC memory. This DPU supports a wide range of network and storage offload functionalities, including RoCE v2, NVMe-oF, and IPsec/TLS acceleration. It also features advanced security protocols like AES and SHA for data protection, as well as secure boot. The DPU is programmable using the DOCA SDK and provides remote management capabilities via an integrated BMC with Redfish and PLDM support.
NVIDIA BlueField-2 - This is a specialized network processor (DPU), which integrates the functions of a switch, system controller, and hardware accelerator. The device is based on the architecture with multi-core Armv8-A processors and is equipped with network adapters NVIDIA ConnectX-6 Dx with Ethernet or Infiniband support at speed up to 200 GbIT/with. intended to offload the central processor by performing infrastructure tasks at the hardware level.
BlueField-2 Supports isolation of key functions - including encryption, firewalls, routing, storage management and network resource virtualization.
Built -in security mechanisms correspond to the Zero Trust concept that prevents unauthorized access. Hardware acceleration can significantly reduce data delays and increase overall bandwidth while reducing power consumption.
Software ecosystem NVIDIA DOCA Provides compatibility with modern development tools and allows us to create user services to manage network, security and storage. Supports virtualization, containerization and adaptation to cloud environments.
BlueField-2 Applied in Date Centers, Artificial Intelligence Systems, Cloud Infrastructures and Telecommunication Equipment. The device provides stable operation under high loads and important calculations, supporting stable operation of services 24/7.
The architecture of the device is scaled, allowing it to be used as part of individual servers, and in complex distributed infrastructures. High density of function integration makes Bluefield-2 a universal solution to build reliable and safe computing environments.
Specifications Nvidia BlueField-2 Ethernet DPU 900-9D208-0076-ST6:
| Parameter | Specification |
|---|---|
| Model Number | 900-9D208-0076-ST6 |
| Product Family | NVIDIA BlueField-2 DPU |
| Network Interface | Dual 25GbE SFP28 |
| Host Interface | PCIe Gen4 x16 |
| Processor | Dual 8-core ARM Cortex-A72 (16 cores total) |
| Memory | 16GB DDR4 ECC |
| Flash Storage | Embedded eMMC, optional microSD |
| Security Acceleration | AES, SHA, IPsec, TLS, Secure Boot |
| Virtualization Support | SR-IOV, VirtIO, container and VM support |
| Storage Offload | NVMe-oF Target and Initiator |
| Network Offload | RoCE v2, VirtIO-net, SRv6, OVS Offload |
| Programmability | DOCA SDK, programmable data-path |
| Remote Management | Integrated BMC, Redfish & PLDM protocols |
| Power Consumption | ~30W (typical) |
| Form Factor | PCIe Full-Height, Single-Slot |
| Compliance | PCIe Gen4, RoHS, CE, FCC |
| condition | new |
|---|
