Nvidia BlueField-2 Ethernet DPU 900-9D218-0073-ST1
NVIDIA BlueField-2 DPU, model 900-9D218-0073-ST1, integrates dual 100GbE QSFP28 network ports, PCIe Gen4 x16 host interface, 8-core ARMv8 A72 CPU, and 16GB ECC DDR4 memory. It supports SR-IOV, VirtIO, NVMe-oF, IPsec, RoCE v2, and features hardware accelerators for offloading networking, security, and storage tasks, with BMC-based remote management.
NVIDIA BlueField-2 - This is a specialized network processor (DPU), which integrates the functions of a switch, system controller, and hardware accelerator. The device is based on the architecture with multi-core Armv8-A processors and is equipped with network adapters NVIDIA ConnectX-6 Dx with Ethernet or Infiniband support at speed up to 200 GbIT/with. intended to offload the central processor by performing infrastructure tasks at the hardware level.
BlueField-2 Supports isolation of key functions - including encryption, firewalls, routing, storage management and network resource virtualization.
Built -in security mechanisms correspond to the Zero Trust concept that prevents unauthorized access. Hardware acceleration can significantly reduce data delays and increase overall bandwidth while reducing power consumption.
Software ecosystem NVIDIA DOCA Provides compatibility with modern development tools and allows us to create user services to manage network, security and storage. Supports virtualization, containerization and adaptation to cloud environments.
BlueField-2 Applied in Date Centers, Artificial Intelligence Systems, Cloud Infrastructures and Telecommunication Equipment. The device provides stable operation under high loads and important calculations, supporting stable operation of services 24/7.
The architecture of the device is scaled, allowing it to be used as part of individual servers, and in complex distributed infrastructures. High density of function integration makes Bluefield-2 a universal solution to build reliable and safe computing environments.
Specifications Nvidia BlueField-2 Ethernet DPU 900-9D218-0073-ST1:
| Parameter | Specification |
|---|---|
| Model Number | 900-9D218-0073-ST1 |
| Product Family | NVIDIA BlueField-2 DPU |
| Network Interface | Dual 100GbE QSFP28 |
| Host Interface | PCIe Gen4 x16 |
| Processor | 8-core ARMv8 A72 |
| Memory | 16GB DDR4 ECC |
| Flash Storage | Embedded eMMC, optional microSD |
| Security Acceleration | IPsec, TLS, AES, SHA, Secure Boot, Hardware Crypto |
| Virtualization Support | SR-IOV, VirtIO, VMs, Containers |
| Storage Acceleration | Full NVMe-oF Support |
| Network Offloads | RoCE v2, OVS, VirtIO-net, Flow Table, SRv6 |
| Programmability | DOCA SDK for DPU pipeline development |
| Remote Management | Integrated BMC, Redfish API, PLDM |
| Power Consumption | ~35W (typical) |
| Form Factor | PCIe Dual-Slot Full-Height |
| Compliance | PCIe Gen4, RoHS, CE, FCC |
| condition | new |
|---|
