Nvidia ConnectX-7 Adapter Card 900-9X7AH-0039-STZ
The NVIDIA ConnectX-7 Adapter Card (P/N: 900-9X7AH-0039-STZ, OPN: MCX715105AS-WEAT) is a high-performance, single-port QSFP112 adapter designed for PCIe Gen4/5 x16 slots. It supports 400GbE Ethernet protocols, providing ultra-low latency and high throughput for modern cloud, AI, and enterprise workloads.
NVIDIA® ConnectX®-7 400G Adapters are high-speed switching equipment of a new generation designed for modern infrastructures of Date Centers. These adapters support Infiniband and Ethernet protocols as well as data transmission speeds up to 400 gigabits per second ( GbIT/with). ConnectX-7 It is an ideal solution for the implementation of advanced, scaled and safe network solutions that meet the needs of both traditional corporate infrastructures and the most demanding loads associated with artificial intelligence, scientific calculations and hypermasted cloudy datacies.
One of the key benefits ConnectX-7 There is a wide support for software, hardware accelerated network, relevant and security functions. These opportunities allow organizations to upgrade and defend their IT infrastructure. Adapters not only provide high productivity, but also increase the security of the network, which is important for protecting data in the conditions of constantly increasing threats. They are ideal for data processing centers and cloud solutions, providing a high level of flexibility and productivity at all stages of work with data.
ConnectX-7 Guarantees ultra -delay and extremely high bandwidth that makes it indispensable for tasks that require maximum data transmission speed such as scientific calculations, large data processing and machine learning. Adapters are equipped with innovative computing engines NVIDIA In-Network Computing, which provide the necessary acceleration and scalability for modern scientific computing workloads. It does ConnectX-7 Ideal for users who need reliable and high -speed equipment to perform the most difficult tasks.
Besides, ConnectX-7 significantly reduces the total cost of possession by increasing the overall efficiency of the system and reducing the load on the network and servers. This solution is not only a powerful tool for performing complex computing tasks, but also an important element in strategic terms of ensuring stability and safety of IT infrastructures in the face of data growth and processing.
Specifications Nvidia ConnectX-7 Adapter Card 900-9X7AH-0039-STZ:
| Parameter | Specification |
|---|---|
| Product Name | NVIDIA ConnectX-7 Adapter Card |
| Part Number (SKU) | 900-9X7AH-0039-STZ |
| Form Factor | Half Height, Half Length (HHHL) |
| Interface | PCI Express 4.0/5.0 x16 |
| Port Configuration | Single-Port QSFP112 |
| Maximum Bandwidth | 400GbE |
| SerDes Type | PAM4 (100Gb/s per lane) |
| Bracket Type | Tall Bracket |
| Supported Features | Host Management, Secure Boot |
| Virtualization | SR-IOV, VirtIO with Hardware Acceleration |
| Offloading Technology | ASAP² (Accelerated Switching and Packet Processing), GPUDirect Storage, TLS/IPsec/MACsec offload |
| Message Rate | Up to 330 million messages/sec (via DPDK) |
| Supported Operating Systems | Linux, Windows, VMware (with MLNX_OFED and WinOF-2 drivers) |
| Target Workloads | Cloud, AI/ML, HPC, Storage, Virtualization, Security |
| Compliance | PCIe Gen4/5, IEEE 802.3, RoHS |
| condition | new |
|---|
