Nvidia ConnectX-8 SuperNIC 900-9X81Q-00CN-ST0
The NVIDIA ConnectX-8 SuperNIC model 900-9X81Q-00CN-ST0 is designed for high-performance networking and supports both Ethernet and InfiniBand protocols. It features dual 200GbE ports, delivering exceptional throughput for data-intensive applications. This network interface card (NIC) is powered by the latest generation of NVIDIA's Ethernet technologies, offering hardware offloading for network functions such as RoCE v2, IPsec, and encryption.
ConnectX-8 SuperNIC – It is a high -speed switching equipment intended for large -scale computing tasks in the field of artificial intelligence. With support of both infiniband and Ethernet-net with a bandwidth 800 GbIT/s, this network interface provides ultra-fast and efficient communication, significantly increasing the performance of systems in data centers and on cloud platforms.
This product is ideal for creating high -yielding infrastructures that support huge computing loads. ConnectX-8 SuperNIC Provides stable work of modern II platforms, supporting the calculations using thousands of graphic processors (GPU). This allows you to organize effective and scaled systems for processing and analyzing large data, as well as for use in the field of automated II-Wicks.
Key features ConnectX-8 SuperNIC There is high energy efficiency and the ability to scroll. He provides up to 800 GbIT/with connectivity that enables solutions for AI factories and cloud data centers that require large computing power. ConnectX-8 SuperNIC supports advanced routing and telemetry capabilities to monitor network loads, which contributes to optimal work with AI loads.
Infiniband's interfaces ConnectX-8 SuperNIC can work with technology NVIDIA SHARP (Scalable Hierarchical Aggregation and Reduction Protocol), which provides high-efficiency data processing directly in the network. This is especially important in highly productive computing environments where performance and performance critical.
Eventually, ConnectX-8 SuperNIC – This is a reliable choice for creating advanced IT infrastructures that will provide long-term support for the most demanding II-operations.
Specifications Nvidia ConnectX-8 SuperNIC 900-9X81Q-00CN-ST0:
| Parameter | Specification |
|---|---|
| Model Number | 900-9X81Q-00CN-ST0 |
| Product Family | NVIDIA ConnectX-8 SuperNIC |
| Network Interface | Dual 200GbE Ports (Ethernet/InfiniBand) |
| Host Interface | PCIe Gen5 x16 |
| Processor | Multi-core processor for packet processing |
| Memory | Integrated memory for offload functionality |
| Security Offload | IPsec, TLS, RoCE v2, encryption offload |
| Virtualization Support | SR-IOV, Virtual Switches |
| Storage Offload | NVMe-oF Target and Initiator |
| Network Offload | RoCE v2, IPsec offload, TCP/UDP processing |
| Programmability | DOCA SDK, custom packet processing |
| Form Factor | PCIe Full-Height, Single-Slot |
| Power Consumption | ~35W (typical) |
| Compliance | RoHS, CE, PCIe Gen5, InfiniBand (compliant with 200GbE) |
| Advanced Features | Network function offloading, high throughput, low latency |
| Remote Management | Supported via BMC and Redfish |
| condition | new |
|---|
