Power supply Cisco C9600-PWR-2KWAC
Hot-pluggable / redundant AC power supply for Catalyst 9600 Series (C9606R chassis)
Switches Cisco Catalyst series 9600 specifically designed to ensure that there is a scale with the most complete in the field of protection and allow your business to grow with minimal total operating costs. Built on Catalyst 9000, Series Catalyst 9600 offers scale and security when it is always needed.
Switches Catalyst series 9600 provide security features that protect the integrity of hardware and software, as well as all data passing through the switch. It provides fault resistance that ensures uninterrupted work of your business. Combined with open API-interfaces Cisco IOS XE and technology programming UADP ASIC Switches Catalyst series 9600 give you what you need now, with the protection of investment in future innovations.
Schedule of power supply Cisco C9600-PWR-2KWAC:
| Specification | Cisco C9600‑PWR‑2KWAC |
|---|---|
| Type | Hot-pluggable / redundant AC power supply for Catalyst 9600 Series (C9606R chassis) |
| Rated Output Power | 2,000 W |
| Output Voltage / Current | 12 V DC @ 167 A |
| Input Voltage Range | 90–140 VAC and 180–264 VAC, 47–63 Hz (cisco.com, router-switch.com) |
| Maximum Input Current | 10.5 A @ 115 VAC (approx. 1,050 W)7.8 A @ 230 VAC (2,000 W) |
| Efficiency | ~94% (typical, 80 PLUS Titanium equivalent) |
| Input Connector | IEC 60320 C16 |
| Power Cord Options | Cisco CAB-TA series by region (e.g., CN, EU, UK, US) |
| Output Holdup Time | ≥ 20 ms |
| Mean Time Between Failures (MTBF) | ~300,000 hours |
| Weight | 1.2 kg (2.65 lb) |
| Heat Dissipation | ~683 BTU/hr |
| Hot-Swap Capability | Supported – module can be replaced without shutting down chassis |
| Compatibility | Catalyst C9606R chassis and variants (C9606R-10A, -1A, etc.); supports mixed AC/DC power supply bays |
| condition | new |
|---|
