Power supply Cisco C9600-PWR-2KWDC
Hot-pluggable / redundant DC power supply for Catalyst 9600 Series (C9606R chassis)
Switches Cisco Catalyst series 9600 specifically designed to ensure that there is a scale with the most complete in the field of protection and allow your business to grow with minimal total operating costs. Built on Catalyst 9000, Series Catalyst 9600 offers scale and security when it is always needed.
Switches Catalyst series 9600 provide security features that protect the integrity of hardware and software, as well as all data passing through the switch. It provides fault resistance that ensures uninterrupted work of your business. Combined with open API-interfaces Cisco IOS XE and technology programming UADP ASIC Switches Catalyst series 9600 give you what you need now, with the protection of investment in future innovations.
Schedule of power supply Cisco C9600-PWR-2KWDC:
| Specification | Cisco C9600‑PWR‑2KWDC |
|---|---|
| Type | Hot-pluggable / redundant DC power supply for Catalyst 9600 Series (C9606R chassis) |
| Rated Output Power | 2,000 W @ 12 VDC |
| Input Voltage Range | −40 to −72 VDC (extended to −75 VDC) (cisco.com, itbargaincenter.com, cisco.com) |
| Maximum Input Current | 60 A @ −40 VDC |
| Efficiency | ~94% (80 PLUS Titanium-class) |
| Output Holdup Time | ≥ 5 ms at 1,200 W output |
| Operating Temperature | −5 °C to +45 °C; Storage: −40 °C to +70 °C |
| Altitude Range | Operates up to 10,000 ft (derate above 6,000 ft) |
| Humidity Range | Operating: 5–90%; Storage: 5–95% (non-condensing) |
| Heat Dissipation | ~6,830 BTU/hr (683 BTU/hr per 200 W scaled) * |
| Dimensions / Weight | Pluggable module, ~1.2 kg (similar to AC models) ** |
| Hot-Swap Capability | Yes – no chassis shutdown required |
| Compatibility | Catalyst C9606R chassis; supports mixed AC/DC supply bays |
| condition | new |
|---|
