Power supply Cisco C9600-PWR-3KWAC
Hot-pluggable / redundant AC power supply for Catalyst 9600 Series chassis
Switches Cisco Catalyst series 9600 specifically designed to ensure that there is a scale with the most complete in the field of protection and allow your business to grow with minimal total operating costs. Built on Catalyst 9000, Series Catalyst 9600 offers scale and security when it is always needed.
Switches Catalyst series 9600 provide security features that protect the integrity of hardware and software, as well as all data passing through the switch. It provides fault resistance that ensures uninterrupted work of your business. Combined with open API-interfaces Cisco IOS XE and technology programming UADP ASIC Switches Catalyst series 9600 give you what you need now, with the protection of investment in future innovations.
Specifications of the switch Cisco C9600-PWR-3KWAC:
| Specification | Cisco C9600‑PWR‑3KWAC |
|---|---|
| Type | Hot-pluggable / redundant AC power supply for Catalyst 9600 Series chassis |
| Rated Output Power | 3,000 W |
| Output Voltage / Current | 12 V DC @ 250 A |
| Input Voltage Range | 90–140 VAC and 180–264 VAC, 47–63 Hz |
| Maximum Input Current | 17.6 A @ 115 VAC (≈ 1,500 W), 17.6 A @ 230 VAC (3,000 W) (cisco.com, provantage.com) |
| Efficiency | ~94% (80 PLUS Titanium certified) |
| Power Supply Input Connector | IEC 60320 C20 |
| Power Cord Options | Multiple country-specific cords (C20‑C19 jumper, 16–20 A variants) |
| Mean Time Between Failures | 300,000 hours |
| Hot-Swap Support | Yes – can be installed/removed without shutdown |
| Compatibility | Catalyst C9606R chassis and variants (C9606R-10A, C9606R-1A, etc.) |
| Warranty | Covered under Catalyst 9600 Enhanced Limited Lifetime Warranty (E‑LLW) |
| condition | new |
|---|
