Router Huawei NetEngine 8000E M1C
SKU
NetEngine 8000E M1C
EAN:
21468
Condition:
new
Stock:
available on order
Lead time:
25-35 days
Huawei NetEngine 8000E M1C is a compact 1U fixed-configuration router delivering 344 Gbit/s bidirectional switching capacity, with support for up to 28 physical ports including 10GE and GE/FE, designed for space-sensitive access or aggregation deployments.
Category: Huawei Router
Routers Huawei NetEngine used in individual, private corporate networks of different sizes. The height of the apparatus varies from 2 U to 4 U, And the depth of the units at the same time is everything 220 mm, This feature of switches allows you to significantly save space in the hardware room..
Routers function Huawei NetEngine in a very wide range of temperatures that varies within - 40 up to + 60 degrees, which allows operation in complex, harsh environments.
Technical features:
- Unique chips of their own development Huawei Provide increased information transmission speeds
- «Hard» IP The channel improves the quality of services of a separate IP line
- Unique technologies IP FPM and hardware function BFD allow you to quickly and most importantly determine the fault and its character
- Architecture SDN, Performs a balanced distribution of traffic, increases the efficiency of using the bandwidth
| Specification | Detail |
|---|---|
| Product Name | Huawei NetEngine 8000E M1C |
| Switching Capacity (Bidirectional) | 344 Gbit/s |
| Forwarding Performance | 78 Mpps |
| Cabinet / Rack Standards | ETSI (21-inch); IEC (19-inch); IMB (3U) |
| Chassis Height | 1U |
| Dimensions (H × W × D) without packaging | 44.5 mm × 442 mm × 220 mm |
| Dimensions with packaging | 255 mm × 585 mm × 390 mm |
| Weight without packaging | ~ 3.9 kg (AC version) / ~ 3.8 kg (DC version) |
| Weight with packaging | ~ 6.1 kg (AC) / ~ 6.0 kg (DC) |
| Typical Power Consumption | ~ 89.2 W (AC) / ~ 89.0 W (DC) |
| Heat Dissipation (Typical) | ~ 289 BTU/hour (AC) / ~ 289 BTU/hour (DC) |
| Availability / Reliability | MTBF ~ 45–46 years; MTTR ~ 2 hours; Availability ~ 0.99999 |
| CPU | 8-core 1.5 GHz |
| Memory | 4 GB |
| Flash Memory | 64 MB |
| Storage | 8 GB |
| Power Supply Mode | 1+1 redundancy (AC or DC) |
| Rated Input Voltage | AC: 100-127 V / 200-240 V (dual-live wire); DC: –48 V / –60 V |
| Input Voltage Range | AC: 100-240 V; DC: –40 V to –72 V |
| Maximum Input Current | ~ 4 A (AC); ~ 10 A (DC) |
| Fans / Cooling | 3 built-in fans; if one fan fails can operate short term at up to ~50°C; airflow left to right; air-cooling |
| Noise (Normal Temperature) | ~ 55 dB(A) |
| Operating Temperature (Long-Term) | −40°C to +65°C |
| Storage Temperature | −40°C to +70°C |
| Operating Humidity (Long-Term) | 5% to 95% RH, non-condensing |
| Storage Humidity | 5% to 100% RH, non-condensing |
| Operating Altitude | ≤ 4,000 m |
| Storage Altitude | < 5,000 m |
| Max Number of Physical Ports | 28 |
| Max Number of 10GE Ports | 16 |
| Max Number of GE Ports | 28 |
| Max Number of FE Ports | 28 |
| Max Number of Electrical Ports | 4 |
| condition | new |
|---|
