Router Huawei NetEngine 8000E X4
SKU
NetEngine 8000E X4
EAN:
21458
Condition:
new
Stock:
available on order
Lead time:
25-35 days
Huawei NetEngine 8000E / 8000 X4 4 Tbps per slot (upgradable up to 19.2 Tbps)
Category: Huawei Router
Routers Huawei NetEngine used in individual, private corporate networks of different sizes. The height of the apparatus varies from 2 U to 4 U, And the depth of the units at the same time is everything 220 mm, This feature of switches allows you to significantly save space in the hardware room..
Routers function Huawei NetEngine in a very wide range of temperatures that varies within - 40 up to + 60 degrees, which allows operation in complex, harsh environments.
Technical features:
- Unique chips of their own development Huawei Provide increased information transmission speeds
- «Hard» IP The channel improves the quality of services of a separate IP line
- Unique technologies IP FPM and hardware function BFD allow you to quickly and most importantly determine the fault and its character
- Architecture SDN, Performs a balanced distribution of traffic, increases the efficiency of using the bandwidth
| Specification | Detail |
|---|---|
| Product Name | Huawei NetEngine 8000E / 8000 X4 |
| Switching Capacity | 173.15 Tbps |
| Forwarding Performance | 24,424 Mpps |
| Maximum Board Capability | 4 Tbps per slot (upgradable up to 19.2 Tbps) |
| Capacity Density (Gbps per U) | 17,668 Gbps/U |
| Main Control Board Redundancy | 2 boards, 1:1 redundancy |
| Switch Fabric Units (SFU) | 8 units, 7 + 1 redundancy |
| Line Card / Slot Count | 4 line card slots |
| Power Modules | Up to 6 modules, N+1 redundancy |
| Fan Modules | 6 fans, 5 + 1 redundancy |
| Dimensions (H × W × D) | 435.6 mm (9.8U) × 442 mm × 861.4 mm |
| Typical Power Consumption | 5,913 W |
| Weight (Fully Configured) | 186.2 kg |
| condition | new |
|---|
