Router Huawei NetEngine A816 E
Huawei NetEngine A816 E is a compact 1U fixed-interface enterprise router with 16 Gbps bidirectional switching capacity. It features up to 8 Gigabit/Fast Ethernet ports, very low power consumption (~24 W), natural cooling (fanless), and supports redundant power inputs.
Routers Huawei NetEngine used in individual, private corporate networks of different sizes. The height of the apparatus varies from 2 U to 4 U, And the depth of the units at the same time is everything 220 mm, This feature of switches allows you to significantly save space in the hardware room..
Routers function Huawei NetEngine in a very wide range of temperatures that varies within - 40 up to + 60 degrees, which allows operation in complex, harsh environments.
Technical features:
- Unique chips of their own development Huawei Provide increased information transmission speeds
- «Hard» IP The channel improves the quality of services of a separate IP line
- Unique technologies IP FPM and hardware function BFD allow you to quickly and most importantly determine the fault and its character
- Architecture SDN, Performs a balanced distribution of traffic, increases the efficiency of using the bandwidth
| Specification | Detail |
|---|---|
| Product Name | Huawei NetEngine A816 E |
| Device Type | Fixed-interface enterprise router / access device |
| Chassis Height | 1 U |
| Dimensions (H × W × D) (without packaging) | 43.6 mm × 320 mm × 210 mm |
| Dimensions with packaging | 90 mm × 465 mm × 380 mm |
| Weight (without packaging) | ~ 2.0 kg |
| Typical Power Consumption | ~ 24.1 W |
| Heat Dissipation (Typical) | ~ 78.06 BTU/hour |
| MTBF | ~ 233.02 years |
| MTTR | ~ 2 hours |
| Availability | ~ 0.99999 |
| CPU | Quad-core, 950 MHz |
| Memory (RAM) | 2 GB SDRAM |
| Flash Memory | 16 MB |
| Storage | 1 GB |
| Power Supply Mode | AC built-in, plus external power adapter (for redundancy and alternative inputs) |
| Rated Input Voltage | AC: 110-220 V; DC: 12 V (via external adapter) |
| Input Voltage Range | AC: 100-240 V; DC: about 11.4-12.7 V |
| Maximum Input Current | AC: ~ 0.5 A; DC (12 V): ~ 2.5 A |
| Redundancy Features | Dual power input supported (built-in AC + external adapter), external adapter for DC inputs; no fan (natural cooling) |
| Noise (Acoustic Power) | No fan → essentially silent under normal temperature |
| Switching Capacity (Bidirectional) | 16 Gbps |
| Maximum Number of Physical Ports | 8 ports |
| Maximum Number of GE Ports | 8 (Gigabit Ethernet) |
| Maximum Number of FE Ports | 8 (Fast Ethernet) |
| Operating Temperature (Long-Term) | −5 °C to +50 °C |
| Storage Temperature | −40 °C to +70 °C |
| Operating Humidity (Long-Term) | 5% RH to 95% RH, non-condensing |
| Storage Humidity | 5% RH to 100% RH, non-condensing |
| Operating Altitude | ≤ 4,000 m |
| Storage Altitude | < 5,000 m |
| Cabinet Installation Standards | ETSI (21-inch); IEC (19-inch); IMB (3U) |
| condition | new |
|---|
