Router Huawei NetEngine AR6710- H4T4X2Y7
SKU
NetEngine AR6710- H4T4X2Y7
EAN:
21478
Condition:
new
Stock:
available on order
Lead time:
25-35 days
Huawei NetEngine AR6710‑H4T4X2Y7 Fixed enterprise router (branch / campus gateway / data center)
Category: Huawei Router
Routers Huawei NetEngine used in individual, private corporate networks of different sizes. The height of the apparatus varies from 2 U to 4 U, And the depth of the units at the same time is everything 220 mm, This feature of switches allows you to significantly save space in the hardware room..
Routers function Huawei NetEngine in a very wide range of temperatures that varies within - 40 up to + 60 degrees, which allows operation in complex, harsh environments.
Technical features:
- Unique chips of their own development Huawei Provide increased information transmission speeds
- «Hard» IP The channel improves the quality of services of a separate IP line
- Unique technologies IP FPM and hardware function BFD allow you to quickly and most importantly determine the fault and its character
- Architecture SDN, Performs a balanced distribution of traffic, increases the efficiency of using the bandwidth
| Specification | Detail |
|---|---|
| Product Name | Huawei NetEngine AR6710‑H4T4X2Y7 |
| Device Type | Fixed enterprise router (branch / campus gateway / data center) |
| Routing Performance (NAT + ACL + QoS, IMIX) | 13 Gbps |
| IPSec Performance (IMIX) | 10 Gbps |
| IPSec Performance (1420‑byte packets) | 28 Gbps |
| SD-WAN Performance (IMIX) | 8 Gbps |
| SD-WAN Performance (1400‑byte packets) | 25 Gbps |
| WAN Ports | 2 × 25GE SFP28, 4 × 10GE SFP+, 4 × GE RJ45 |
| LAN Ports | 2 × 25GE SFP28, 4 × 10GE SFP+, 4 × GE RJ45 |
| Expansion Slots (SIC) | 6 |
| WSIC Slots | 1 |
| CPU | 12 cores, 1.5 GHz |
| Memory (RAM) | 8 GB |
| Flash / Storage | Built-in HDD |
| Management Ports | 1 × RJ‑45 console, 1 × USB 3.0 |
| Chassis Height | 1U |
| Dimensions (H × W × D) | 43.9 mm × 442 mm × 420 mm |
| Weight | 5.61 kg (without packaging), 8.82 kg (with packaging) |
| Power Supply | Built-in AC/DC, 100–240 V AC or –48 V DC |
| Typical Power Consumption | 65 W |
| Maximum Power Consumption | 67 W |
| Operating Temperature | 0 °C to +45 °C |
| Operating Humidity | 5%–95% RH, non-condensing |
| MTBF (Mean Time Between Failures) | 52.58 years |
| MTTR (Mean Time To Repair) | 2 hours |
| Availability | 0.9999956580 |
| condition | new |
|---|
