Router Huawei NetEngine AR8700-8
Huawei NetEngine AR8700-8 is a high-reliability enterprise router optimized for SD-WAN and campus network egress scenarios. It delivers 30 Gbps of forwarding performance with full support for IPSec, dual MPUs for redundancy, flexible port configurations (including 40GE, 10GE, GE), strong reliability, and moderate power consumption in a 2U chassis.
Routers Huawei NetEngine used in individual, private corporate networks of different sizes. The height of the apparatus varies from 2 U to 4 U, And the depth of the units at the same time is everything 220 mm, This feature of switches allows you to significantly save space in the hardware room..
Routers function Huawei NetEngine in a very wide range of temperatures that varies within - 40 up to + 60 degrees, which allows operation in complex, harsh environments.
Technical features:
- Unique chips of their own development Huawei Provide increased information transmission speeds
- «Hard» IP The channel improves the quality of services of a separate IP line
- Unique technologies IP FPM and hardware function BFD allow you to quickly and most importantly determine the fault and its character
- Architecture SDN, Performs a balanced distribution of traffic, increases the efficiency of using the bandwidth
| Specification | Detail |
|---|---|
| Product Name | Huawei NetEngine AR8700-8 |
| Model / Part Number | AR8700-8 / Part Number: 02355LFN |
| Device Type | Enterprise / campus SD-WAN router |
| Forwarding Performance (NAT + ACL + QoS, IMIX) | 30 Gbps |
| IPSec Performance (IMIX) | 20 Gbps |
| IPSec Performance (1420-byte packets) | 50 Gbps |
| SD-WAN IPSec Performance (IMIX) | 24 Gbps |
| SD-WAN Performance (1400-byte packets) | 60 Gbps |
| Typical SD-WAN Performance (IMIX) | 15.5 Gbps |
| Typical SD-WAN Performance (1400-byte) | 40 Gbps |
| Fixed WAN Ports | 1 × 40GE QSFP+; 8 × 10GE SFP+; 8 × GE Combo (all can be configured as LAN) |
| Expansion Slots | 8 × SIC slots; WSIC: default 0, maximum 4 |
| Memory | SPU: 16 GB; MPU: 8 GB |
| Flash Memory (MPU) | 4 GB |
| Rack / Chassis Height | 2 U |
| Dimensions without packaging (H × W × D) | 88.1 mm × 442.0 mm × 482.8 mm |
| Dimensions with packaging | 205 mm × 585 mm × 760 mm |
| Weight without packaging | 15 kg |
| Weight with packaging | 18.7 kg |
| Number of Service Board Slots | 8 |
| Redundancy for MPUs | 1:1 redundancy (dual MPUs) |
| Power Supply | 2 power modules, support both AC / DC / HVDC inputs |
| Typical Power Consumption | 221 W |
| Maximum Power Consumption | 288 W |
| Fans | Pluggable fan module(s) |
| Airflow / Cooling Mode | Air cooling; airflow direction supports front-to-rear and left-to-rear depending on installation |
| Noise (Acoustic Power, Normal Temp) | ~ 57.6 dB(A) |
| Operating Temperature (Long-Term) | 0 °C to +45 °C |
| Storage Temperature | −40 °C to +70 °C |
| Operating Humidity (Long-Term) | 5% to 95% RH, non-condensing |
| Storage Humidity | same range, non-condensing |
| Operating Altitude | ≤ 5,000 m |
| MTBF (Mean Time Between Failures) | ~ 33.83 years |
| MTTR (Mean Time To Repair) | 2 hours |
| Availability | ~ 0.9999932515 |
| condition | new |
|---|
