Router Huawei NetEngine40E-X3A
SKU
NetEngine40E-X3A
EAN:
21472
Condition:
new
Stock:
available on order
Lead time:
25-35 days
The Huawei NetEngine40E-X3A is a compact 6U chassis universal service router offering ~2.76 Tbps switching capacity and ~1,071 Mpps forwarding performance.
Category: Huawei Router
Routers Huawei NetEngine used in individual, private corporate networks of different sizes. The height of the apparatus varies from 2 U to 4 U, And the depth of the units at the same time is everything 220 mm, This feature of switches allows you to significantly save space in the hardware room..
Routers function Huawei NetEngine in a very wide range of temperatures that varies within - 40 up to + 60 degrees, which allows operation in complex, harsh environments.
Technical features:
- Unique chips of their own development Huawei Provide increased information transmission speeds
- «Hard» IP The channel improves the quality of services of a separate IP line
- Unique technologies IP FPM and hardware function BFD allow you to quickly and most importantly determine the fault and its character
- Architecture SDN, Performs a balanced distribution of traffic, increases the efficiency of using the bandwidth
| Specification | Detail |
|---|---|
| Product Name | Huawei NetEngine40E-X3A |
| Switching Capacity | 2.76 Tbps |
| Forwarding Performance | 1071 Mpps (million packets per second) |
| LPU (Line Processing Unit) Slots | 3 |
| MPU (Main Processing Unit) Slots | 2 (1:1 redundancy) |
| Service Board Slots | 3 |
| Power Supply Redundancy | 1+1 redundant power modules |
| Chassis Height (Rack Units) | 6U |
| Dimensions (H × W × D) (without packaging) | 264 mm × 442 mm × 710 mm (chassis body) |
| Dimensions with attachments | ~ 264 mm × 442 mm × 758–770 mm (with cable trays & front/rear attachments) |
| Weight without packaging | ~ 34.4 kg (base chassis) |
| Weight (full configuration) | ~ 72.1–74.7 kg |
| Typical Power Consumption (Full Config) | ~ 1120 W |
| Heat Dissipation (Typical Full Config) | ~ 3633.8 BTU/hour |
| MTBF (Mean Time Between Failures) | ~ 22.85 years |
| MTTR (Mean Time To Repair) | ~ 0.5 hour |
| Availability | ~ 0.9999975 |
| Operating Temperature (Long-Term) | 0 °C to +45 °C |
| Operating Temperature (Short-Term) | –5 °C to +55 °C |
| Storage Temperature | –40 °C to +70 °C |
| Operating Humidity (Long-Term) | 5% to 85% RH, non-condensing |
| Short-Term Operating Humidity | 5% to 95% RH, non-condensing |
| Storage Humidity | 5% to 95% RH |
| Operating Altitude | ≤ 4,000 m |
| Storage Altitude | < 5,000 m |
| Power Supply Mode / Rated Input Voltage | AC version: 200-240 V; DC version: –48 V / –60 V |
| Input Voltage Range | AC: 180-264 V; DC: –40 V to –72 V |
| Noise (Acoustic Power, Normal Temp) | NEBS-compliant; < 78 dB(A) at 27 °C |
| condition | new |
|---|
