Model
|
N8500
|
|
Technical characteristics of equipment
|
|
Architecture
|
Multi-node cluster architecture Active-Active
|
|
Number of nodes
|
2 – 24
|
|
Cache/node
|
Basic version: 16 GB
standard version: 24 GB
Enterprise version: 48 GB
extended version: 96 GB / 192 GB
|
|
GE Ports/node
|
Standard configuration: 4 x GE, before 16 x GE
|
|
10 GE Ports/node
|
before 6 x 10 GE
|
|
Disk type
|
SAS, NL SAS, SSD
|
|
Physical capacity
|
Dynamically expandable up to 15 PB
|
|
Software features
|
|
levels RAID
|
0, 1, 3, 5, 6, 10, 50
|
|
File system size
|
Dynamically expandable to 256 Tb
|
|
Maximum number of shots
|
512 (for file system)
|
|
Network storage protocols
|
FC, FCoE, iSCSI, NFS, CIFS, FTP, HTTP
|
|
Access control
|
NIS, Microsoft Active Directory, LDAPВ
|
|
Other protocols
|
NDMP LAN-FREE, SNMP, NTP, SMI-S
|
|
Value Added Functions
|
DST (dynamic storage), Snapshot, Mirror, Quota, Replication, WORM, SmartCache (Dynamic data caching technology), HyperThin (subtle provision), HyperImage (snapshot), HyperCopy (copy LUN), HyperClone (split mirror) and HyperMirror (synchronous / asynchronous remote replication)
|
|
Quota
|
NFS/CIFS soft/hard
|
|
Control mode
|
GUI, CLI
|
|
Compatible operating systems
|
Windows, Linux, Mac OS, Solaris, AIX, and HP-UX
|
|
Alarm modes
|
Email, SNMP, and Syslog
|
|
physical characteristics
|
|
Source of power
|
AC: 100 V up to 127 V/ 200 V up to 240V
DC: –48 V to -60 V
|
|
Power consumption
|
Engine
|
? 830 W> (cluster with two nodes)
|
|
storage block
|
Controller case: ? 830 W>; Drive Enclosure: ? 550 W>
|
|
Dimensions (H x W x D)
|
Engine
|
4U, 175 mm x 446 mm x 502 mm (cluster with two nodes)
|
|
storage block
|
2U, Controller case: 86,1 mm x 446 mm x 582 mm
4U, Controller case: 175 mm x 446 mm x 502 mm
2U, Drive Enclosure: 86,1 mm x 446 mm x 412 mm
4U, Drive Enclosure: 175 mm x 446 mm x 412 mm
|
|
Frame
|
42U, 205 cm x 57.5 cm x 118 cm
|
|
The weight
|
Engine
|
Dual core cluster engine NAS: ? 43,6 kg
|
|
storage block (in full configuration)
|
2U, Controller case ?29,9 kg / Frame
4U, Controller case ?43,6 kg / Frame
2U, Drive Enclosure ?26,5 kg / Frame;
4U, Drive Enclosure ?42.64 kg / Frame
|
|
Working temperature
|
5В°C do 40В°C
|
|
Operating Humidity
|
5%В up to 90% relative humidity
|
