Switch Arista DCS-7050TX3-48C8-F
24995 $
Arista 7050X3, 48x10GBaseT & 8x100GbE QSFP switch, front-to-rear air, 2xAC
A series of switches Arista 7050X3 designed for the implementation of high-performance networks of the next generation, where speed, scalability and minimal delays are critical. These devices are optimized for the tasks of modern date centers, cloud platforms and corporate media with high traffic density. Support for 10G, 25G, 50G and 100G Ethernet speeds provides configuration flexibility and the ability to smoothly migrate to more modern standards without the need for a complete infrastructure replacement.
Switches 7050X3 built on an architecture using high-performance Broadcom Trident 3 chips, which achieves high throughput and re >Auded network behavior for any load. The devices have a port density of up to 64×100G in one unity that makes them an effective solution for traffic aggregation and implementation Spine/Leaf-Structures with a high degree of scalability.
Operating system Arista EOS Provides stability, controllability and integration with modern automation systems. Supports protocols such as VXLAN, EVPN and BGP, as well as broad opportunities for telemetry, streaming monitoring and microsegmentation. It makes a series 7050X3 suitable for building complex multi-cloud and virtualized environments with increased requirements for security and fault tolerance.
Energy efficiency is achieved by the intellectual cooling system and the low heat dissipation at the high density of ports. Switches are equipped with spawn power supplies and hot replacement fans, which significantly simplifies maintenance and reduces the risks of simple. Ability to choose the direction of air flow (back and forth or back) Allows you to take into account the features of placing equipment in racks and meet the requirements of centralized cooling.
Specifications of the switch DCS-7050TX3-48C8-F:
| Category | Specification |
|---|---|
| Model | DCS-7050TX3-48C8-F |
| Series | 7050X3 |
| Form Factor | 1RU (Rack Unit) |
| Airflow | Front-to-Rear |
| Port Configuration | 48 x 10GBASE-T (RJ-45), 8 x 100G QSFP28 |
| Maximum Ports | Up to 48 x 10GbE and 8 x 100GbE; breakout up to 72 x 10GbE total |
| Performance | 6.4 Tbps switching, 2.4 Bpps forwarding, < 3 µs latency |
| Buffering | 32 MB dynamic buffer |
| CPU | Quad-core x86 |
| System Memory | 16 GB |
| Flash Storage | 16 GB |
| Management Ports | 1 x RJ-45 Management, 1 x Serial Console, 1 x USB |
| Power Supplies | Dual 500W AC hot-swappable, redundant |
| Typical Power Draw | ~450W |
| Maximum Power Draw | 700W |
| Input Voltage | 100–240V AC |
| Input Frequency | 50/60 Hz |
| Efficiency | Platinum (up to 93%) |
| Cooling | 4 x hot-swappable fans (N+1 redundancy) |
| Dimensions (WxHxD) | 19 x 1.75 x 20 in (48.3 x 4.4 x 50.8 cm) |
| Weight | ~22 lbs (10 kg) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -25°C to 70°C |
| Relative Humidity | 5% to 95% non-condensing |
| Operating Altitude | Up to 10,000 ft (3,000 m) |
| Layer 2 Features | 802.1Q VLANs, MLAG, STP/RSTP/MSTP, LACP, Jumbo Frames |
| Layer 3 Features | Static Routing, OSPF, BGP, VRF, IPv4/IPv6, ECMP |
| Advanced Features | VXLAN, QoS (8 queues), ACLs, CoPP |
| Management & Automation | EOS, eAPI, ZTP, CloudVision, SNMP, CLI, JSON-RPC |
| Telemetry | LANZ, sFlow, OpenConfig, streaming telemetry |
| Standards Compliance | FCC Class A, EN55032, EN61000, RoHS, UL, CE |
| Minimum EOS Version | 4.21.1F or later |
| condition | new |
|---|
