Switch Arista DCS-7060CX2-32S-F
29995 $
Arista 7060X2, 32x100GbE QSFP & 2xSFP+ switch, front-to-rear air, 2xAC, 2xC13-C14 cords
Switches Arista 7060X2 Series — It is a high -performance solution for new generation networks with support 10G, 40G and 100G Ethernet. Designed specifically for data centers, where high throughput, minimal delays and scalability are important. Ideal for architecture Spine/Leaf, as well as for cloud and corporate networks.
The switches are equipped with 32 ports 100GbE QSFP28 or koMbinvented ports 10/40/100GbE, which provides flexibility in the design and modernization of network infrastructure. Supports key protocols L2/L3, including VXLAN, BGP, OSPF, EVPN and MLAG, which ensures reliable routing and traffic segmentation in scalable networks.
Based on the operating system Arista EOS implemented stable operation, support for automation and centralized management through CloudVision, CLI and API. High energy efficiency, thoughtful cooling and variable fans provide reliable operation with minimal cost.
Equipment is certified and tested. Even without deep technical knowledge you can easily integrate a switch into a network. And experts will appreciate the functions of streaming telemetry, PTP support and advanced monitoring for critical important tasks.
Specifications of the switch Arista DCS-7060CX2-32S-F:
| Category | Specification |
|---|---|
| Model | Arista DCS-7060CX2-32S-F |
| Switching Capacity | 6.4 Tbps |
| Forwarding Rate | 4.76 billion packets per second (Bpps) |
| Port Configuration | 32 x 100G QSFP28 ports |
| Breakout Options | Up to 128 x 10G or 25G ports via breakout cables |
| CPU | Dual-Core x86 |
| System Memory | 8 GB |
| Flash Storage | 4 GB |
| Packet Buffer | 22 MB Shared Buffer |
| Latency | As low as 450 ns (nanoseconds) |
| Power Supplies | Dual redundant, hot-swappable (1+1) |
| Cooling Fans | N+1 redundant, hot-swappable |
| Airflow Direction | Front-to-Rear (denoted by F in model name) |
| Typical Power Draw | ~500W |
| Max Power Draw | ~700W |
| Dimensions (W x H x D) | 19 x 1.75 x 18 inches (48.3 x 4.4 x 45.7 cm) |
| Weight | ~19.8 lbs (9 kg) |
| Mounting | Standard 1U rack-mountable |
| Management Ports | 1 x RJ-45 management, 1 x RJ-45 serial console, 1 x USB |
| EOS Version Required | EOS 4.20.1F or later |
| MAC Addresses | 288K |
| IPv4 / IPv6 Routes | 32K / 16K |
| VLANs | 4096 |
| Jumbo Frame Support | Up to 9216 bytes |
| QoS | 8 priority queues per port |
| Traffic Engineering | PFC, ECN, DCBX, ETS |
| Time Synchronization | IEEE 1588 PTP, NTP |
| Telemetry | sFlow, Streaming Telemetry, LANZ |
| Certifications | RoHS, UL/CSA, CE, FCC Class A, VCCI, BSMI, C-Tick |
| Warranty & Support | Lifetime Limited Warranty (LLW) with TAC access depending on support plan |
| condition | new |
|---|
