Switch Arista DCS-7060CX2-32S-R
29995 $
Arista 7060X2, 32x100GbE QSFP & 2xSFP+ switch, rear-to-front air, 2xAC, 2xC13-C14 cords
Switches Arista 7060X2 Series — It is a high -performance solution for new generation networks with support 10G, 40G and 100G Ethernet. Designed specifically for data centers, where high throughput, minimal delays and scalability are important. Ideal for architecture Spine/Leaf, as well as for cloud and corporate networks.
The switches are equipped with 32 ports 100GbE QSFP28 or koMbinvented ports 10/40/100GbE, which provides flexibility in the design and modernization of network infrastructure. Supports key protocols L2/L3, including VXLAN, BGP, OSPF, EVPN and MLAG, which ensures reliable routing and traffic segmentation in scalable networks.
Based on the operating system Arista EOS implemented stable operation, support for automation and centralized management through CloudVision, CLI and API. High energy efficiency, thoughtful cooling and variable fans provide reliable operation with minimal cost.
Equipment is certified and tested. Even without deep technical knowledge you can easily integrate a switch into a network. And experts will appreciate the functions of streaming telemetry, PTP support and advanced monitoring for critical important tasks.
Specifications of the switch Arista DCS-7060CX2-32S-R:
| Category | Specification |
|---|---|
| Model | Arista DCS-7060CX2-32S-R |
| Switching Capacity | 6.4 Tbps |
| Forwarding Rate | 3.3 billion packets per second (Bpps) |
| Port Configuration | 32 x 100GbE QSFP100 ports, 2 x 10GbE SFP+ ports |
| Breakout Options | Each QSFP port supports 100GbE, 40GbE, 4x10GbE, 4x25GbE, or 2x50GbE |
| Latency | As low as 450 nanoseconds (ns) in cut-through mode |
| Packet Buffer | 22 MB shared buffer pool |
| CPU | Dual-Core x86 |
| System Memory | 8 GB |
| Flash Storage | 4 GB |
| Management Ports | 1 x RJ-45 Ethernet, 1 x RJ-45 Serial Console, 1 x USB Type-A |
| Power Supplies | 2 x 500W AC (PWR-500AC-R), hot-swappable, included |
| Cooling Fans | 4 x FAN-7000-R modules, hot-swappable, included |
| Airflow Direction | Back-to-Front (denoted by "R" in model name) |
| Dimensions (W x H x D) | 19 x 1.75 x 16 inches (48.3 x 4.4 x 40.6 cm) |
| Weight | Approximately 21 lbs (9.5 kg) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -25°C to 70°C (-13°F to 158°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Operating Altitude | 0 to 10,000 ft (0 to 3,000 m) |
| MAC Address Table Size | Up to 136,000 entries |
| VLANs | 4096 |
| Jumbo Frame Support | Up to 9216 bytes |
| Quality of Service (QoS) | 8 priority queues per port |
| Traffic Engineering | PFC, ECN, DCBX, ETS |
| Time Synchronization | IEEE 1588 PTP, NTP |
| Telemetry | sFlow, Streaming Telemetry, LANZ |
| Minimum EOS Version | EOS 4.20.1F or later |
| Certifications | RoHS, UL/CSA, CE, FCC Class A, VCCI, BSMI, C-Tick |
| condition | new |
|---|
