Switch Arista DCS-7150S-64-CL-F
29995 $
Arista 7150S, 48x10GbE (SFP+) & 4xQSFP+ switch with clock, front-to-rear air, 2xAC, 2xC13-C14 cords
Switches Arista 7150 Series — These are the advanced solutions for creating high-speed and reliable networks in Date Centers, Corporate Networks and Cloud Infrastructures. These devices support standards 10 Gigabit Ethernet (10GbE) and 40 Gigabit Ethernet (40GbE), which provides high bandwidth up to several terabits per second.
The technical features of the 7150 series include the use of specialized ASIC-chips with technology support Cut-Through Switching, which reduces packet transmission latency to a record 650 nanoseconds. Such minimal delay is especially important for financial institutions, data processing centers and other businesses with critical response time requirements.
Switches come up to 48 ports 10GbE SFP+, which allow using optical or copper modules for connection flexibility, as well as multiple ports 40GbE QSFP+, which enables traffic aggregation and ensures network scalability. Supports channel aggregation (LACP) and different switching protocols, including VLAN, STP, RSTP and MSTP, which enables building reliable and secure network topologies.
Built -in support Quality of Service (QoS) Allows you to prioritize important traffic by ensuring stable work of critical applications. Energy consumption is optimized with modern technologies that reduces the operating costs of equipment.
Switches management is implemented on the basis of the operating system Arista EOS, which supports configuration automation via API, scripts and integration with network management systems. This makes work with the equipment convenient for both experienced administrators and users with basic knowledge.
Arista 7150 devices have certificates of compliance with international quality and safety standards, which confirms their reliability and long service life.
Specifications of the switch Arista DCS-7150S-64-CL-F:
| Feature | Specification |
|---|---|
| Model | Arista DCS-7150S-64-CL-F |
| Series | Arista 7150S Series |
| Ports | 48 × 1/10GbE SFP+ ports, 4 × 40GbE QSFP+ uplink ports |
| Switching Capacity | 1.28 Tbps |
| Forwarding Rate | 960 million packets per second (Mpps) |
| Latency | As low as 380 nanoseconds (ns) |
| MAC Address Table Size | Up to 64,000 entries |
| Packet Buffer | 9.5 MB dynamically allocated |
| CPU | Dual-Core x86 processor |
| System Memory | 4 GB DRAM |
| Flash Storage | 2 GB |
| Management Ports | 1 × RJ-45 Ethernet, 1 × RJ-45 Serial Console, 1 × USB Type-A |
| Airflow Direction | Front-to-Rear (denoted by "F" in model name) |
| Power Supplies | 2 × 460W AC (PWR-460AC-F), hot-swappable, included |
| Cooling Fans | 4 × FAN-7000-F modules, hot-swappable, included |
| Dimensions (W × H × D) | 17.5" × 1.75" × 16" (44.5 cm × 4.4 cm × 40.6 cm) |
| Weight | Approximately 19 lbs (8.6 kg) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Operating Altitude | 0 to 10,000 ft (0 to 3,000 m) |
| Operating System | Arista EOS (Extensible Operating System), version 4.10.0 or later required |
| Certifications | RoHS, UL/CSA, CE, FCC Class A, VCCI, BSMI, C-Tick |
| condition | new |
|---|
