Switch Arista DCS-7160-48YC6-F
23995 $
Arista 7160, High Capacity 48 x 25GbE SFP and 6 x 100GbE QSFP switch, front to rear air, 2 x AC and 2 x C13-C14 cords
Switches Arista 7160 Series — These are new generation network devices designed to meet the growing requirements for speed, scalability and energy efficiency in corporate and cloud environments. Supports speeds from 10 to 100 GbIT/s, they provide flexible connectivity and adaptation to changes in the infrastructure without the need for a complete modernization of the network.
Technical Benefits of Series 7160 are based on specialized architecture using your own chips (ASIC) and innovative technologies Arista. The devices support 10GbE, 25GbE, 40GbE and 100GbE interfaces, the total bandwidth reaches 6,4 TbIT/s, and the performance reaches 2.5 billion packets per second. Thanks to deep buffering technology (Deep Buffering) Switches effectively cope with peak load traffic without data loss.
The models are equipped with up to 64 ports QSFP28 at a speed of 100gbe and also support KOMbInvasive connection options to 10/25/40GbE. This allows to achieve high port density while maintaining a compact form factor. Supports protocols VXLAN, EVPN, MLAG, BGP, OSPF, as well as routing, virtualization and integration functions into cloud services.
Operating system Arista EOS Provides stable work and wide functionality for automation, control and monitoring. EOS Supports API, Python-scripts, integration with ANSIBLE, PUPPET and continuous update (ISSU), which greatly simplifies working with devices in DevOps environments.
Switches have energy efficient architecture with modular power sources and fans that can be replaced without stopping work. This provides high availability and adaptability to variables. The equipment is certified in accordance with international standards confirming its reliability, safety and durability.
Specifications of the switch Arista DCS-7160-48YC6-F:
| Feature | Specification |
|---|---|
| Model | Arista DCS-7160-48YC6-F |
| Series | Arista 7160 Series |
| Form Factor | 1U Rackmount |
| Ports | 48 × SFP+/SFP28 ports (supporting 1/10/25 GbE) |
| 6 × QSFP+/QSFP28 ports (supporting 40/100 GbE) | |
| Switching Capacity | 3.6 Terabits per second (Tbps) |
| Forwarding Rate | 2.4 billion packets per second (Bpps) |
| Latency | As low as 2 microseconds |
| MAC Address Table Size | Up to 128,000 entries |
| Packet Buffer Memory | 24 MB dynamically allocated |
| CPU | Quad-Core x86 processor |
| System Memory (RAM) | 8 GB DRAM |
| Flash Storage | 4 GB |
| Management Ports | 1 × RJ-45 Ethernet, 1 × RJ-45 Serial Console, 2 × USB Type-A |
| Airflow Direction | Front-to-Back (denoted by “-F” suffix) |
| Power Supplies | 2 × 500W AC (PWR-500AC-F), hot-swappable, included |
| Cooling Fans | 4 × FAN-7000-F, hot-swappable, included |
| Operating System | Arista EOS (Extensible Operating System), version 4.20.0 or later required |
| Certifications | RoHS, UL/CSA, CE, FCC Class A, VCCI, BSMI, C-Tick |
| Dimensions (W × H × D) | 19" × 1.75" × 20.6" (48.3 cm × 4.4 cm × 52.3 cm) |
| Weight | Approximately 22 lbs (10 kg) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Relative Humidity | 5% to 95% non-condensing |
| Operating Altitude | 0 to 10,000 ft (0 to 3,000 m) |
| condition | new |
|---|
