Switch Arista DCS-7280CR3-32D4-R
74995 $
Arista 7280R3, 32x100GbE QSFP and 4x400GbE QSFP-DD switch router, rear to front air, 2 x AC
Switches Arista 7280R Gigabit Ethernet Universal Leaf Platform This is a professional solution for new generation networks. The devices of this series combine high throughput, low latency, wide scalability and support for modern protocols, including VXLAN, EVPN, BGP and MPLS, which makes them ideal for both data centers and enterprise networks of any scale.
Switches Arista 7280R They are equipped with high -speed ports 10/25/40/100GbE, Supports Deep Buffering up to 16 GB, and also offer basic and extended routing L2/L3, which is especially important for stability under high loads. Architecture EOS (Extensible Operating System) provides not only management flexibility but also seamless integration with existing infrastructure thanks to API-interfaces and automation.
These devices have certification CE, FCC and RoHS, which confirms their compliance with international reliability and security standards. Thanks to the modular design and dual power supplies, the switches are easily scalable and have high fault tolerance.
Arista 7280R - The choice of professionals, but is accessible and understandable to ordinary users, thanks to the ease of installation, intuitive interface and detailed technical support. This equipment is worth investing if you value the speed, stability and future of your networks.
Built -in telemetry and analytics capabilities allow administrators to track the network parameters in real time, including delays, package losses and transmitting lane, which is especially important for critical services with critical services SLA. support Arista CloudVision Provides centralized control and visualization by simplifying scaling and updating. Switches are compatible with technology Zero Touch Provisioning (ZTP) and linux-oriented Devops tools that makes them perfect for automated date centers.
Arista 7280R have proven themselves well in the fields of finance, telecommunications, media, as well as in scientific and educational institutions where data transfer speed and reliability are critical. Thanks to a well-thought-out architecture and active support from the manufacturer, the devices are easily updated and adapted to growing requirements, including support IPv6, QoS and segmentation of the security policy network.
Specifications of the switch Arista DCS-7280CR3-32D4-R:
| Category | Specification |
|---|---|
| Model | Arista DCS-7280CR3-32D4-R |
| Series | 7280R3 Series |
| Form Factor | 1U Rack-mountable |
| Dimensions (H x W x D) | 4.4 cm x 48.3 cm x 55.8 cm (1.75 in x 19 in x 22 in) |
| Weight | 12.3 kg (27 lbs) |
| Airflow | Rear-to-front (R) |
| Ports | |
| Management Interfaces | |
| Throughput | Up to 12.8 Tbps |
| Packets per Second | Up to 4.8 Bpps |
| Latency | As low as 450 ns |
| Packet Buffer | 64 MB shared buffer pool |
| MAC Address Table | 224,000 entries |
| Jumbo Frame Support | Up to 9216 bytes |
| Memory | |
| Routing Table Capacity | |
| VLANs | 4096 |
| LAG Groups | 1152 |
| ACL Entries | 24,000 |
| Priority Queues per Port | 8 |
| MLAG Support | Up to 128 ports |
| Routing Protocols | OSPF, IS-IS, RIP-2, BGP, IGMPv2/v3, VRRP, PIM-SM/SSM, static IP routing, GRE, OSPFv3, Multiprotocol BGP, Bidirectional PIM, MSDP, ECMP, policy-based routing (PBR), MLDv2, Bidirectional Forwarding Detection (BFD), URPF, Virtual ARP (VARP), RSVP, BGP-MP |
| Management Protocols | SNMP v1/v2/v3, RMON, Telnet, SSH-2, CLI |
| Advanced Features | |
| Power Supply | |
| Power Consumption | 535 Watts (operational) |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating Humidity | 5% to 95% (non-condensing) |
| Compliance Standards | IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.3ba, IEEE 802.1Qbb, IEEE 1588-2008, IEEE 802.3by, IEEE 802.3bs, IEEE 802.3cm |
| Certifications | VCCI, C-Tick, BSMI, EN 61000-3-2, EN 61000-3-3, EN55024, CB, CCC, EMC, FCC, UL 60950-1, IEC 60950-1, KC, NRTL, EAC, RoHS 2011/65/EU, EMC 2004/108/EC, LVD 2006/95/EC, WEEE 2012/19/EU, EN 300 386, EN 62368-1, IEC 62368-1, EN 55032, EN 55035, CSA 60950-1 |
| Warranty | Limited warranty - 1 year |
| condition | new |
|---|
