Feature
|
Specification
|
|
Model
|
JL365A
|
|
Product Name
|
Aruba 2930M 48G POE+ 1-slot Switch
|
|
Form Factor
|
Rack-mountable
|
|
Ports
|
48 RJ-45 autosensing 10/100/1000 POE+ ports
|
|
PoE Power
|
370W (upgradable with additional power supplies)
|
|
Expansion Slots
|
1 modular slot for stacking or uplink modules
|
|
Uplink Options
|
Supports optional 1GbE, 10GbE, and 40GbE uplinks
|
|
Switching Capacity
|
176 Gbps
|
|
Forwarding Capacity
|
130.9 Mpps
|
|
Memory
|
2GB DDR3 SDRAM, 1GB flash
|
|
Latency
|
< 2.8 µs (64-byte packets)
|
|
Management
|
Web GUI, CLI, SNMP, IMC, AirWave, Cloud-based (Central)
|
|
Stacking
|
Up to 10 switches, up to 400 Gbps stacking bandwidth
|
|
IPv6
|
IPv6 host, dual stack (IPv4/IPv6), IPv6 management, IPv6 routing
|
|
Layer 3 Features
|
Static routing, RIP, Access OSPF
|
|
Security
|
ACLs, IEEE 802.1X, MAC authentication, port security, DHCP snooping
|
|
Quality of Service (QoS)
|
Advanced classifier-based QoS, layer 4 prioritization, traffic prioritization
|
|
Energy Efficient Ethernet
|
IEEE 802.3az
|
|
Operating Temperature
|
0°C to 45°C (32°F to 113°F)
|
|
Operating Humidity
|
15% to 95% (non-condensing)
|
|
Power Supply
|
Includes 1 modular power supply, supports redundant power supply
|
|
Dimensions
|
44.25 x 38.15 x 4.39 cm (17.42 x 15.02 x 1.73 in)
|
|
Weight
|
4.84 kg (10.67 lb)
|
|
Warranty
|
Limited Lifetime Warranty, with next-business-day replacement (NBD)
|
