Switch Aruba (HPE) JL687A

SKU
JL687A
Call for Price
EAN: 18888
Stock: available on order
Lead time: 25-35 days

Aruba CX 6400 48-port 1G/10GBASE-T and 4-port QSFP+ 1.92 Tbps Switch

Switches HPE Aruba Networking CX 8400 is a high-performance and scalable solution for large enterprises and data centers. They provide reliable, flexible and high-performance operation of network services.

Switches CX 8400 have a modular architecture, supporting up to 8 modules, which allows you to increase the power and capacity of the network as needed. Bandwidth up to 19,2 Tbit/with delivers high performance for the most demanding applications. Operating system ArubaOS-CX provides advanced automation and analytics features, including monitoring, problem prediction and automatic remediation.

Switches CX 8400 are characterized by high reliability due to redundancy mechanisms such as dual power supply and backup fans. Built-in security features protect the network from threats and attacks, and support for modern network technologies such as VXLAN, BGP EVPN and MACsec makes them an ideal solution for hybrid and multi-cloud networks.


Technical specifications of the switch Aruba (HPE) JL687A:


Feature

Specification

Model

JL687A

Product Name

Aruba CX 6400 48-port 1G/10GBASE-T and 4-port QSFP+ 1.92 Tbps Switch

Form Factor

Rack-mountable

Ports

48 RJ-45 autosensing 1G/10GBASE-T ports

Uplink Ports

4 QSFP+ ports (40GbE/100GbE)

Switching Capacity

1.92 Tbps

Forwarding Capacity

1,428 Mpps

Memory

16GB DDR4 SDRAM, 16GB flash

Latency

< 2.0 µs (64-byte packets)

Management

Aruba NetEdit, Web GUI, CLI, SNMP, REST API, Ansible, Python

Stacking

Virtual Switching Extension (VSX), no physical stacking cables required

IPv6

IPv6 host, dual stack (IPv4/IPv6), IPv6 management, IPv6 routing

Layer 3 Features

BGP, OSPF, IS-IS, Static routing, PIM-SM/DM, VRF, ECMP, BFD

Security

ACLs, IEEE 802.1X, MAC authentication, port security, DHCP snooping, IP source guard

Quality of Service (QoS)

Advanced classifier-based QoS, layer 4 prioritization, traffic prioritization, Weighted Fair Queuing (WFQ)

Energy Efficient Ethernet

IEEE 802.3az

Operating Temperature

0°C to 45°C (32°F to 113°F)

Operating Humidity

10% to 90% (non-condensing)

Power Supply

Dual modular power supplies, hot-swappable, field-replaceable

Dimensions

44.55 x 50.5 x 4.35 cm (17.54 x 19.88 x 1.71 in)

Weight

8.6 kg (18.96 lb)

Warranty

Limited Lifetime Warranty, with next-business-day replacement (NBD)

This table summarizes the critical specifications and features of the Aruba CX 6400 JL687A switch. If
