Switch Aruba (HPE) JL701C

Specifications

JL701C Datasheet

Power Consumption Description

425W (Max Power) 120W (Idle Power)

Heat Dissipation

1,450 BTU/hr

Routing/switching Capacity

2.4 Tbps

Switch Fabric Speed

2.4 Tbps

Routing Capabilities

Static (IPv4/IPv6): RIPv2; RIPng; OSPF; OSPFv3; BGP-4; MP-BGP with IPv6; PBR; ECMP; GRE, MPLS

Switching Capacity

2.4 Tbps

Throughput

2,678 Mpps

Memory and Processor

CPU: 1.8 GHz 4-core 64-bit; RAM: 16 GB; Flash/Storage: 32 GB; Packet Buffer: 32 MB

Power Supply Name

2 field-replaceable and hot-swappable power supplies depends on the model

Management Features

RJ-45 serial and USB-C console; RJ-45 Ethernet port; USB-Type A

Warranty Standard Statement

Limited Lifetime Warranty See https://www.arubanetworks.com/support-services/product-warranties/ for warranty and support information included with your product purchase.

Weight (imperial)

18.05 lb

Weight (metric)

8.19 kg

Product Dimensions (imperial)

1.73 x 17.4 x 16.0 in

Product Dimensions (metric)

4.40 x 4.42 x 40.6 cm
