Switch Aruba (HPE) JL701C
39860 $
JL701C Aruba 8360v2- 32Y4C MACsec Powerto-Port 3 Fans, 2 Power Supplies
A series of highly intelligent and high-performance switches Aruba CX 8360 can be used for both corporate campus cores and data centers that require server-over-rack connectivity and aggregation of scale-out, rack-to-rack, spine, and leaf topologies.
Switch Specifications Aruba JL701C:|
Specifications |
|
|
JL701C Datasheet |
|
|
Power Consumption Description |
425W (Max Power) 120W (Idle Power) |
|
Heat Dissipation |
1,450 BTU/hr |
|
Routing/switching Capacity |
2.4 Tbps |
|
Switch Fabric Speed |
2.4 Tbps |
|
Routing Capabilities |
Static (IPv4/IPv6): RIPv2; RIPng; OSPF; OSPFv3; BGP-4; MP-BGP with IPv6; PBR; ECMP; GRE, MPLS |
|
Switching Capacity |
2.4 Tbps |
|
Throughput |
2,678 Mpps |
|
Memory and Processor |
CPU: 1.8 GHz 4-core 64-bit; RAM: 16 GB; Flash/Storage: 32 GB; Packet Buffer: 32 MB |
|
Power Supply Name |
2 field-replaceable and hot-swappable power supplies depends on the model |
|
Management Features |
RJ-45 serial and USB-C console; RJ-45 Ethernet port; USB-Type A |
|
Warranty Standard Statement |
Limited Lifetime Warranty See https://www.arubanetworks.com/support-services/product-warranties/ for warranty and support information included with your product purchase. |
|
Weight (imperial) |
18.05 lb |
|
Weight (metric) |
8.19 kg |
|
Product Dimensions (imperial) |
1.73 x 17.4 x 16.0 in |
|
Product Dimensions (metric) |
4.40 x 4.42 x 40.6 cm |
| condition | new |
|---|
