Switch Cisco C9300-24T-M
Modular uplinks supporting 1/10 G SFP+ and 40 G QSFP+
Switches of the ruler Cisco Catalyst – ITelectual and flexible network solutions with fixed configuration characteristics, a wide line of modules to solve issues with the correct operation of the LAN. Network communicators make it possible to simplify the operation of IT infrastructure, guarantee the safety of business processes, ensure uninterrupted network functioning.
New Switches Cisco Catalyst 9300 series implements the convergence of the Internet of Things with an industry-leading level of scalability, providing up to 384 ports with a power of up to 60W for UPOE, as well as POE+ and PoE, high security, support for the AVB protocol and the IEEE 1588 standard, service analysis and classification for Internet applications.
Switches Cisco Catalyst 9300 Provide intellectual, simple and maximally safe access by integrated wireless network controller. They can work in high -density conditions by standard 802.11ac the second wave (48 access points) and at the same time differ in compactness (form factor 1 RU).
The main advantages of the series 9300:
-
High mastabas with access points Wave2;
-
Processor Intel x86;
-
Intellectual power management using technology Cisco StackPower;
-
Support for dual stack for distribution IPv4/IPv6;
-
The latest operating system Cisco IOS XE;
-
Extended security functionality.
Specifications of the switch Cisco C9300-24T-M:
| Specification | Details |
|---|---|
| Product Name | Cisco Catalyst 9300‑24T‑M |
| Form Factor | Fixed 1RU switch with modular uplink bays; 3 hot-swappable fans; dual redundant power supplies supported |
| Downlink Ports | 24 × 1 GbE RJ‑45 copper ports (non‑PoE) |
| Uplink Slots | Modular uplinks supporting 1/10 G SFP+ and 40 G QSFP+ |
| Stacking | StackWise‑480 (480 Gbps backplane); uses 2 dedicated stacking ports; supports up to 8 switches |
| StackPower | Supported for power pooling across stack |
| Switching Capacity | 208 Gbps switching capacity; ~154.8 Mpps forwarding |
| Performance Features | AES‑256 MACsec, Flexible NetFlow, NBAR2, ETA, Cisco ThousandEyes via DNA Advantage |
| Cloud Management | Managed through Meraki Dashboard (license required); Adaptive Policy segmentation |
| Power & PoE | Default PSU: 350 W AC (PWR‑C1‑350WAC‑P‑M); PSU idle/max draw: 79.2 W / 99 W; non‑PoE |
| Physical Dimensions | 1.73″ × 17.5″ × 17.7″ (4.4 × 44.5 × 44.9 cm) including default PSU & fans |
| Weight | 16.03 lb (7.27 kg) with default PSU & fans |
| Operating Conditions | –5 °C to +45 °C; 5–90% humidity (non-condensing) |
| Regulatory Compliance | FCC Class A, ICES-003 Class A, CISPR22/32, EN 300 386, EN 55022/32, EN 55024, UL/CSA/IEC 60950-1, RoHS compliant |
| Use Case | Ideal for high-performance enterprise access, fiber uplink aggregation, and cloud-managed campus deployments (“smart building”, Wi‑Fi 6) |
| condition | new |
|---|
