Switch Cisco C9300-24UX-M
24 × Multigigabit (up to 10 GbE) RJ‑45 with UPoE support (60 W per port, IEEE 802.3bt Type 3)
Switches of the ruler Cisco Catalyst – ITelectual and flexible network solutions with fixed configuration characteristics, a wide line of modules to solve issues with the correct operation of the LAN. Network communicators make it possible to simplify the operation of IT infrastructure, guarantee the safety of business processes, ensure uninterrupted network functioning.
New Switches Cisco Catalyst 9300 series implements the convergence of the Internet of Things with an industry-leading level of scalability, providing up to 384 ports with a power of up to 60W for UPOE, as well as POE+ and PoE, high security, support for the AVB protocol and the IEEE 1588 standard, service analysis and classification for Internet applications.
Switches Cisco Catalyst 9300 Provide intellectual, simple and maximally safe access by integrated wireless network controller. They can work in high -density conditions by standard 802.11ac the second wave (48 access points) and at the same time differ in compactness (form factor 1 RU).
The main advantages of the series 9300:
-
High mastabas with access points Wave2;
-
Processor Intel x86;
-
Intellectual power management using technology Cisco StackPower;
-
Support for dual stack for distribution IPv4/IPv6;
-
The latest operating system Cisco IOS XE;
-
Extended security functionality.
Specifications of the switch Cisco C9300-24UX-M:
| Specification | Details |
|---|---|
| Model | Cisco Catalyst C9300‑24UX‑M |
| Ports | 24 × Multigigabit (up to 10 GbE) RJ‑45 with UPoE support (60 W per port, IEEE 802.3bt Type 3) |
| Modular Uplinks | 10/40 GbE (SFP+, QSFP+) optional |
| Stacking | Dual 120 Gbps hardware stack ports (StackWise‑480) |
| StackPower | Supported in ring topology up to 4 switches |
| Dedicated Management Port | 1 console RJ‑45 port (standard across C9300‑M models) |
| PoE Budget (with default PSU) | 560 W (primary 1100 WAC PSU) |
| PoE with Secondary PSUs | 910 W (350 W secondary), 1275 W (715 W), up to 1440 W (1100 W) |
| Switching Capacity | Up to 480 Gbps stack fabric, 1 Tbps in full StackWise‑1T across C9300X family |
| UADP ASIC | UADP 2.0sec (supports IPsec up to 100 Gbps hardware acceleration on C9300X) |
| Physical Dimensions (H×W×D) | 1.73″ × 17.5″ × 19.2″ (4.4 × 44.5 × 48.8 cm) – consistent with 9300 series |
| Weight | ~7.5 kg (16.6 lb) |
| Rack Mount | Standard 1U rack‑mountable |
| Fans | 3 hot‑swappable with N+1 redundancy |
| Operating Temperature | –5 °C to +45 °C |
| Storage Temperature | –40 °C to +70 °C |
| Humidity | 5% to 90% non‑condensing |
| Altitude | Up to 3,000 m (10,000 ft) @ ≤ +40 °C |
| MTBF @25 °C | ~214,760 hours (~24.5 years) |
| Warranty | Cisco Enhanced Limited Lifetime Hardware Warranty with NBD advanced replacement |
| Software | Cisco IOS XE 16.5.1a+ (C9300X support), Meraki cloud management option |
| condition | new |
|---|
