Switch Cisco C9300-48P-M
Optional modular uplink slots (e.g., C9300‑NM‑2Q‑M for 2×40 GbE, C9300‑NM‑8X‑M for 8×10 GbE)
Switches of the ruler Cisco Catalyst – ITelectual and flexible network solutions with fixed configuration characteristics, a wide line of modules to solve issues with the correct operation of the LAN. Network communicators make it possible to simplify the operation of IT infrastructure, guarantee the safety of business processes, ensure uninterrupted network functioning.
New Switches Cisco Catalyst 9300 series implements the convergence of the Internet of Things with an industry-leading level of scalability, providing up to 384 ports with a power of up to 60W for UPOE, as well as POE+ and PoE, high security, support for the AVB protocol and the IEEE 1588 standard, service analysis and classification for Internet applications.
Switches Cisco Catalyst 9300 Provide intellectual, simple and maximally safe access by integrated wireless network controller. They can work in high -density conditions by standard 802.11ac the second wave (48 access points) and at the same time differ in compactness (form factor 1 RU).
The main advantages of the series 9300:
-
High mastabas with access points Wave2;
-
Processor Intel x86;
-
Intellectual power management using technology Cisco StackPower;
-
Support for dual stack for distribution IPv4/IPv6;
-
The latest operating system Cisco IOS XE;
-
Extended security functionality.
Specifications of the switch Cisco C9300-48P-M:
| Specification | Details |
|---|---|
| Model | Cisco Catalyst C9300‑48P‑M |
| Ports | 48 × 10/100/1000 Mbps RJ‑45 PoE+ ports |
| Modular Uplinks | Optional modular uplink slots (e.g., C9300‑NM‑2Q‑M for 2×40 GbE, C9300‑NM‑8X‑M for 8×10 GbE) |
| Stacking | StackWise‑480: up to 480 Gbps stacking bandwidth with up to 8 switches |
| StackPower | Supported over up to 4 switches via StackPower |
| Management | Meraki cloud-managed dashboard (Adaptive Policy / over-the-wire tagging) |
| Default PSU | 715 W AC (Platinum-rated), hot-swappable |
| PoE Budget (default) | 437 W total PoE with default 715 W PSU |
| PoE Budget (with 1100 W PSU) | Supports up to 1100 W PSU (higher budgets available, detailed in datasheet) |
| PoE per port | IEEE 802.3at PoE+, up to 30 W per port |
| Switching Capacity | 480 Gbps backplane for standalone, full StackWise‑480 capability |
| Physical Dimensions (H×W×D) | 1.73″ × 17.5″ × 19.2″ (4.4 × 44.5 × 48.8 cm) |
| Weight | ~7.5 kg (16.6 lb) |
| Fans | 3 × hot-swappable, N+1 redundancy |
| Operating Temp | –5 °C to +45 °C |
| Storage Temp | –40 °C to +70 °C |
| Humidity | 5 %–90 % non-condensing |
| Altitude | Up to 3,000 m (10,000 ft) at ≤ +40 °C |
| Warranty & Support | Cisco Enhanced Limited Lifetime Hardware Warranty with next-business-day replacement |
| Software Platform | Cisco IOS XE 16.5.1a+ and Meraki management, including Adaptive Policy |
| condition | new |
|---|
