Switch Cisco C9300-48UXM-M
36 × 100 Mb/1 Gb/2.5 Gb + 12 × multigigabit (10G/5G/2.5G/1G/100M) RJ‑45 UPOE – 60 W per port
Switches of the ruler Cisco Catalyst – ITelectual and flexible network solutions with fixed configuration characteristics, a wide line of modules to solve issues with the correct operation of the LAN. Network communicators make it possible to simplify the operation of IT infrastructure, guarantee the safety of business processes, ensure uninterrupted network functioning.
New Switches Cisco Catalyst 9300 series implements the convergence of the Internet of Things with an industry-leading level of scalability, providing up to 384 ports with a power of up to 60W for UPOE, as well as POE+ and PoE, high security, support for the AVB protocol and the IEEE 1588 standard, service analysis and classification for Internet applications.
Switches Cisco Catalyst 9300 Provide intellectual, simple and maximally safe access by integrated wireless network controller. They can work in high -density conditions by standard 802.11ac the second wave (48 access points) and at the same time differ in compactness (form factor 1 RU).
The main advantages of the series 9300:
-
High mastabas with access points Wave2;
-
Processor Intel x86;
-
Intellectual power management using technology Cisco StackPower;
-
Support for dual stack for distribution IPv4/IPv6;
-
The latest operating system Cisco IOS XE;
-
Extended security functionality.
Specifications of the switch Cisco C9300-48UXM-M:
| Specification | Details |
|---|---|
| Model | Cisco Catalyst C9300‑48UXM‑M |
| Ports | 36 × 100 Mb/1 Gb/2.5 Gb + 12 × multigigabit (10G/5G/2.5G/1G/100M) RJ‑45 UPOE – 60 W per port) |
| Modular Uplinks | Optional 10 GbE/25 GbE/40 GbE/100 GbE via network modules (SFP+/QSFP+) |
| Stacking (Data) | StackWise‑480 with up to 480 Gbps stacking bandwidth |
| StackPower | Supported for power sharing/redundancy across up to 4 switches |
| Management | Meraki cloud-managed dashboard with Adaptive Policy and zero-touch provisioning |
| Default Power Supply | 1100 W AC, hot-swappable |
| PoE Budget (Default PSU) | 490 W total, sufficient for full 48-port UPOE |
| Switching Capacity | 580 Gbps switching capacity, 480 Gbps stacking fabric |
| Forwarding Rate | 431.54 Mpps |
| Physical Dimensions (H×W×D) | 1.73″ × 17.5″ × 22.2″ (4.4 × 44.5 × 56.4 cm) including PSU & fans |
| Weight | Approx. 22.2 lb (10.07 kg) with PSU & fans |
| Fans | 3 hot-swappable with N+1 redundancy |
| Operating Temperature | –5 °C to +45 °C |
| Storage Temperature | –40 °C to +70 °C |
| Humidity | 5% to 90% non‑condensing |
| Altitude | Up to 3,000 m (10,000 ft) at ≤ +40 °C |
| Warranty & Support | Cisco Enhanced Limited Lifetime Hardware Warranty with next-business-day replacement |
| Software | Cisco IOS XE 16.5.1a+; Meraki dashboard with Adaptive Policy |
| condition | new |
|---|
