Switch Cisco C9300X-24Y-M
4 modular slots supporting SFP+, SFP28, QSFP+, QSFP28 (1/10/25/40/100 G)
Switches of the ruler Cisco Catalyst – ITelectual and flexible network solutions with fixed configuration characteristics, a wide line of modules to solve issues with the correct operation of the LAN. Network communicators make it possible to simplify the operation of IT infrastructure, guarantee the safety of business processes, ensure uninterrupted network functioning.
New Switches Cisco Catalyst 9300 series implements the convergence of the Internet of Things with an industry-leading level of scalability, providing up to 384 ports with a power of up to 60W for UPOE, as well as POE+ and PoE, high security, support for the AVB protocol and the IEEE 1588 standard, service analysis and classification for Internet applications.
Switches Cisco Catalyst 9300 Provide intellectual, simple and maximally safe access by integrated wireless network controller. They can work in high -density conditions by standard 802.11ac the second wave (48 access points) and at the same time differ in compactness (form factor 1 RU).
The main advantages of the series 9300:
-
High mastabas with access points Wave2;
-
Processor Intel x86;
-
Intellectual power management using technology Cisco StackPower;
-
Support for dual stack for distribution IPv4/IPv6;
-
The latest operating system Cisco IOS XE;
-
Extended security functionality.
Specifications of the switch Cisco C9300X-24Y-M:
| Specification | Details |
|---|---|
| Product Name | Cisco Catalyst 9300X‑24Y‑M |
| Form Factor | Fixed 1RU switch; 3 hot-swappable fans; modular uplink bays |
| ASIC | Dual Cisco UADP 2.0sec ASICs with line-rate 100 Gbps IPsec hardware encryption |
| Downlink Ports | 24 × 1/10/25 G SFP28 fiber ports |
| Uplink Slots | 4 modular slots supporting SFP+, SFP28, QSFP+, QSFP28 (1/10/25/40/100 G) |
| Stacking | StackWise‑1T up to 1 Tbps, supported by dedicated stack ports; supports up to 8-unit stacks |
| StackPower+ | Supported, enabling shared power across stack members |
| Switching Capacity | 2,000 Gbps; forwarding rate ~1,488 Mpps |
| Security & Policy Features | Adaptive Policy tagging, AES‑256 MACsec, NBAR2, ETA, Flexible NetFlow, Cisco ThousandEyes via DNA Advantage |
| Cloud Management | Managed via Meraki Dashboard—Meraki license required |
| Energy Efficiency & Identification | Energy-Efficient Ethernet, per-port PoE control (N/A here), blue beacon LED, embedded RFID tag |
| Dimensions (H×W×D) | 1.73″ × 17.5″ × 20.7″ (4.4 cm × 44.5 cm × 52.6 cm) including fans & PSUs |
| Weight | 16.2 lb (7.32 kg) including default power supplies & fans |
| Operating Conditions | Temperature: –5 °C to +45 °C; Humidity: 5–90% non‑condensing |
| Memory & Storage | 8 GB memory, 16 GB flash; USB support & optional SSD up to 240 GB |
| Performance Highlights | Line-rate 100 Gbps IPsec; deep-buffer architecture; up to 1 TB stacking bandwidth; supports twinax for 10 G connections |
| Use Cases | High-performance fiber aggregation, campus distribution, cloud-managed enterprise, secure multigigabit access mixture environments |
| condition | new |
|---|
