Switch Cisco IE-3500-8T3S-A
IE3500 with 8 GE Copper and 3 GE SFP, Modular, Network Advantage
Switches Cisco IE3500 Rugged Series – These are industrial level -managed devices L2/L3, designed for building fault-tolerant networks under high loads and difficult operating conditions. Equipped with a wide range of interfaces, provide high bandwidth and extended traffic protection and control capabilities. Optimally suited for use at industrial automation, energy, transport, as well as in infrastructure with a high degree of distribution.
Switches of this series are made in a strong metal body with passive cooling and meet the industrial standard IP30. Operating temperature range - from -40°C to +75°C, which enables use in facilities with extreme environmental conditions.
Supported technology Power over Ethernet (PoE/PoE+), which allows transmitting power and data over a single cable, reducing cabling infrastructure. The high power budget for the port allows you to use switches to connect energy-intensive devices-IP cameras, access points, sensors and terminals.
Basic technical features:
- Ethernet gigabit ports with auto -determination of speed;
- Modular slots for SFP/SFP+ – Ability to connect fiber -fiber lines;
- Support for channel aggregation (LAG), the excesses and protocols of faucet resistance (STP, RSTP, MSTP);
- Hardware encryption and protection levels: IEEE 802.1X, DHCP Snooping, Dynamic ARP Inspection, MACsec;
- Support for precise time synchronization protocol IEEE 1588 (PTP);
- Extended management capabilities through CLI, SNMP, Web interface and Cisco IOS;
- Compatibility with centralized management and monitoring systems (Cisco DNA, Industrial Network Director).
The IE3500 Model includes modifications with different number of ports (to 24), as well as versions with high resistance to electromagnetic interference certified by standards IEC 61850-3, IEEE 1613 and other sectoral requirements.
The presence of built -in L3 routing functions allows you to use devices as a switching point but also as a network knot with routing between segments.
The series is intended for use in high -load architectures to transmit data - video surveillance, machine vision, automated control, as well as projects with integration EDGE AI and cloud solutions. The switch architecture supports the functions of virtualization required by modern technological process management systems.
Mechanical body strength, vibration protection, voltage and dust jump.
Cisco IE3500 Rugged Series – This is a new generation solution where productivity, safety, scalability and continuity of work are critical.
Specifications of the switch Cisco IE-3500-8T3S-A:
| Parameter | Description |
|---|---|
| Model | Cisco IE-3500-8T3S-A |
| Series | Cisco IE3500 Rugged Series |
| Form Factor | DIN-rail mountable, modular industrial switch |
| Base Ports | 8 × 10/100/1000BASE-T (RJ-45) + 3 × 1G SFP fiber uplinks |
| Port Expansion | Supported via IEM expansion modules |
| Switching Capacity | Wire-speed performance on all ports |
| MAC Address Table | Up to 24,000 entries |
| Forwarding Rate | Hardware-accelerated, line-rate forwarding |
| RAM (DRAM) | 8 GB |
| Flash Memory | 5.1 GB usable |
| SD Card Support | Optional, up to 16 GB |
| Maximum VLANs | 1,024 active VLANs; up to 4,096 VLAN IDs |
| IPv4 Routes (Indirect) | Up to 7,000 |
| IPv6 Routes (Indirect) | Up to 1,522 |
| IGMP Multicast Groups | Up to 1,024 |
| Access Control Entries | Up to 1,536 (combined PACL, VACL, RACL) |
| Spanning Tree Instances | Up to 128 |
| Jumbo Frame Support | Up to 9,198 bytes (limited to 2,000 bytes for specific protocols) |
| Industrial Protocols | MRP, REP, DLR |
| TSN Support | IEEE 802.1Qbu and IEEE 802.3br frame preemption |
| Security Features | Secure Boot, Cisco TrustSec, Secure Equipment Access, Cyber Vision |
| Monitoring Tools | Embedded Cisco ThousandEyes agent |
| Operating System | Cisco IOS XE |
| Management Options | CLI, Web UI, SNMP, Cisco Catalyst Center, optional Meraki Dashboard |
| License Tier | Network Advantage (indicated by suffix “-A”) |
| Power Input Range | Nominal: 12–48 VDC; Absolute: 9.6–60 VDC |
| Power Consumption | Approximately 29 W (non-PoE configuration) |
| Redundant Power Inputs | Yes (dual DC input supported) |
| Operating Temperature | –40 °C to +75 °C |
| Cooling | Fanless passive cooling |
| Certifications | IEC 61850, IEEE 1613, UL Class I Div 2, ATEX, EN 61000 series |
| Mounting Options | DIN-rail standard; optional panel-mount brackets |
| Dimensions (H × W × D) | Approximately 133 × 145 × 139 mm (excluding expansion modules) |
| Weight | Approx. 2.0 kg (without modules) |
| condition | new |
|---|
