Central and aggregation switches Dell Networking series Z provides the ideal degree of density, versatility and performance for shared and individual data centers.
Series Z consists of a large range of switches with clear fixed form factors. They provide high performance for innovative resource-intensive workloads, and the devices in this series offer resource-intensive reserves for future data center needs.
Uniqueness of switches Dell Networking series Z is not only simplifying management, but also providing resources with the necessary flexibility. Thus, switches from this series are ahead of data processing needs, and do not react to their appearance, as their predecessors do.
With data switches, you can easily create any data center with the ability to connect up to 100 000 servers. Models Z9100-ON and Z9264F-ON support up to 128 ports 10/25GbE.
Z series switches provide scalable performance, without special additional settings. Unique features of Dell Networking series switches Z:
- Multi-speed switches are equipped with ports Ethernet 10, 25, 40, 50 or 100GbE
- The Z9100-ON model has a throughput of up to 6,4 Tbit/with, and Z9264F-ON — Up to 12,8 Tbit/with
- Incredibly low latency — less than a microsecond
- Ability to customize tables for virtualized data centers
Technical specifications of the switch Dell Z9864F-ON:
|
Specification
|
Description
|
|
Model
|
Z9864F-ON
|
|
Form Factor
|
2U
|
|
Ports
|
48 ports of 25GbE SFP28, 8 ports of 100GbE QSFP28
|
|
Performance
|
3.2 Tbps
|
|
Throughput
|
2.38 billion packets per second (Bpps)
|
|
Memory
|
32 GB DRAM, 16 GB flash memory
|
|
Power Consumption
|
850 W (maximum)
|
|
Noise Level
|
74.1 dBA (maximum)
|
|
Operating System
|
Dell EMC Networking OS9
|
|
Management
|
CLI, SNMP, Telnet, SSH, Web GUI
|
|
Dimensions (W x H x D)
|
17.3 x 3.4 x 21.3 inches (440 x 86.5 x 540 mm)
|
|
Weight
|
20.2 kg
|
|
Operating Temperature
|
0°C to 40°C
|
|
Storage Temperature
|
-40°C to 70°C
|
|
Operating Humidity
|
10% to 85% (non-condensing)
|
|
Storage Humidity
|
5% to 95% (non-condensing)
|
|
Additional Features
|
Support for IPv4/IPv6, QoS, policy-based routing, VXLAN support, Network Function Virtualization (NFV), support for VxRail and VCF, integration with VMware and OpenStack
|
|
Security
|
802.1x, ACL, IP address filtering, port-based security
|
|
Redundancy
|
Hot-swappable fans and power supplies
|
