Switch Series HPE Comware - These are turnkey networking solutions that support both traditional and evolving data center architectures..
Switching units of data centers based on HPE Comware!
Switch Models HPE Comware differentiate themselves from their predecessors by increased network performance, reliability and scalability in the data center, campuses and branch offices of various institutions.
The devices are based on a modular operating system Comware, these switches provide enterprise-class availability, they support complex EVPN-based deployments, and VXLAN and provide superior security with encryption MACsec.
Automated, multi-vendor and proactive network management!
As network management becomes more complex and the risks associated with a compromised data stream increase, switches not only provide increased performance, but also protect your personal data and information of your customers as much as possible..
HPE Intelligent Management Center (IMC) provides end-to-end management of multiple service providers at once across branch, campus, and data center networks, scaling to tens of thousands of devices. IMC converts junk network data into useful information to keep you running at the highest possible performance level.
Specifications switch Aruba (HPE) FlexFabric JL585A:
|
I/O ports and slots
|
48 1/10G SFP+ ports
6 x 40GbE ports or 3 x 40GbE ports and 1 x 100G port or 2 x 100GbE por
|
|
Additional ports and slots
|
Management ports: 1 10M/100M/1000MBASE-T copper port, 1 SFP port
Console ports: 1 mini USB console port, 1 serial console port
|
|
Power supplies
|
2 power supply slots
1 minimum power supply required (ordered separately).
Power supplies are hot swappable.
For 1:1 redundancy this system requires two same-type power supplies to function properly
|
|
Fan tray
|
4 fan tray slots
The customer must order fan trays, as they are not included with the switch. This system requires four same-direction airflow fan trays to function properly. A failed fan tray must be replaced immediately. Fans are hot swappable
|
|
Physical characteristics
|
Dimensions: 44 mm x 440 mm x 400 mm (1.73 in. x 17.32 in. x 15.75 in.) (1U height)
Weight: 10 kg (22.05 lb)
|
|
Memory and processor
|
1 GB flash, 4 GB SDRAM; packet buffer size: 12 MB
|
|
Mounting and enclosure
|
Rack Mount 1U
|
|
Performance
|
10 Gbps Latency (64-byte packets)
Throughput up to 1071 Mpps
Switching capacity: 1440 Gbps
Routing table size: 16K entries (IPv4), 8K entries (IPv6)
MAC address table size: 208K entries
ARP table Size: 68K (1K static)
|
|
Reliability
|
MTBF (years): 135.90
|
|
Environment
|
Operating temperature: 32°F to 113°F (0°C to 45°C)
Operating relative humidity: 10% to 90%, noncondensing
Acoustic:Low-speed fan: 52.5 dB; high-speed fan: 68.7 dB
|
|
Electrical characteristics
|
Frequency: 50/60 Hz
Maximum heat dissipation: 607 BTU/hr
Voltage: 100 - 240 VAC, rated
Maximum power rating: 100 VAC-240 VAC; Max. voltage: 264 VAC @ 50 Hz/60 Hz
Max. output power: 250W / 450W depending on PSU selected
Idle power: 74W / 108W
Max. output power: 250W
Idle power is the actual power consumption of the device with no ports connected.
Maximum power rating and maximum heat dissipation are the worst-case theoretical maximum numbers provided for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated.
|
|
Safety
|
UL 60950-1; IEC 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60950-1; AS/NZS 60950-1; CNS 14336-1
|
|
Emissions
|
VCCI Class A; EN 55032 Class A; ICES-003 Class A; AS/NZS CISPR 32 Class A; EN 61000-3-2; EN 61000-3-3; FCC (CFR 47, Part 15) Class A; CISPR 32 Class A; CNS 13438; KN32; TCVN 7189; Anatel Resolution 442; ETSI EN 300-386
|
|
Immunity
|
ETSI EN 300 386; EN 55024; KN35; CISPR 24
|
|
Management
|
IMC; CLI; out-of-band management; SNMP Manager; Telnet; FTP
|
|
Services
|
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for details on the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local Hewlett Packard Enterprise sales office.
|
