Switch Huawei CloudEngine CE5855-48T4XS
SKU
CE5855-48T4XS
EAN:
21453
Condition:
new
Stock:
available on order
Lead time:
25-35 days
Huawei CloudEngine CE5855-48T4XS 48 × 10/100/1000BASE-T (RJ45)
Category: Huawei Switch
Switches Huawei CloudEngine 5800 The series is equipped with 48 1Ge ports and external ports 10ge and 40Ge to combine in stack up to 16 switches. 40GE ports allow you to create a stack of non-blocking switches that covers the physical distance between data centers.
Series switches CE5800 Supports technology TRILL, which provides service delivery flexibility and large-scale virtual machine migrations. System software VRP HUAWEI companies and comprehensive security functions provide reliable and uninterrupted operation and high performance with low cost of operation and maintenance.
Specifications of the switch Huawei CE5855-48T4XS:
| Feature | Specification |
|---|---|
| Model | Huawei CloudEngine CE5855-48T4XS |
| Form Factor | 1 RU, rack-mounted |
| Downlink Ports | 48 × 10/100/1000BASE-T (RJ45) |
| Uplink Ports | 4 × 10GE SFP+ |
| Console Port | RJ45 console port |
| CPU / Processing | Multi-core CPU |
| Memory & Storage | DRAM: 2 GB; Flash: 2 GB |
| Dimensions (W × D × H) | 442.0 × 420.0 × 43.6 mm |
| Weight (device only) | ~ 6.0 kg (excluding optical/power/fan modules) |
| Power Supply Modules | Dual pluggable AC/DC |
| Redundancy | 1+1 power backup |
| Power Consumption (Static) | ~ 65 W |
| Power Consumption (Typical) | ~ 80–100 W |
| Power Consumption (Maximum) | ~ 120 W |
| Heat Dissipation (Static) | ~ 220 BTU/hr |
| Heat Dissipation (Typical) | ~ 340 BTU/hr |
| Heat Dissipation (Maximum) | ~ 410 BTU/hr |
| Number of Fan Modules | 3 hot-swappable fans |
| Airflow Direction Options | Port-side intake or exhaust (depending on modules) |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 132 Mpps |
| System Buffer | 32 MB |
| RTC | Supported |
| USB Deployment | Supported |
| Log Backup | Supported |
| Stacking | Supported (up to 9 devices, iStack technology) |
| Noise (at ~27 °C) | 45–50 dB(A) |
| Operating Conditions | Temp: 0–45 °C; Humidity: 5–95% (non-condensing); Altitude ≤ 5000 m |
| condition | new |
|---|
