Switch Huawei CloudEngine CE5855SL-48T4XS
SKU
CE5855SL-48T4XS
EAN:
21455
Condition:
new
Stock:
available on order
Lead time:
25-35 days
Huawei CloudEngine CE5855SL-48T4XS 48 × 10/100/1000BASE-T (RJ45)
Category: Huawei Switch
Switches Huawei CloudEngine 5800 The series is equipped with 48 1Ge ports and external ports 10ge and 40Ge to combine in stack up to 16 switches. 40GE ports allow you to create a stack of non-blocking switches that covers the physical distance between data centers.
Series switches CE5800 Supports technology TRILL, which provides service delivery flexibility and large-scale virtual machine migrations. System software VRP HUAWEI companies and comprehensive security functions provide reliable and uninterrupted operation and high performance with low cost of operation and maintenance.
Specifications of the switch Huawei CE5855SL-48T4XS:
| Feature | Specification |
|---|---|
| Model | Huawei CloudEngine CE5855SL-48T4XS |
| Form Factor | 1 RU, rack-mounted |
| Downlink Ports | 48 × 10/100/1000BASE-T (RJ45) |
| Uplink Ports | 4 × 10GE SFP+ |
| Console Port | RJ45 console port |
| CPU / Processing | Multi-core CPU |
| Memory & Storage | DRAM: 2 GB; Flash: 2 GB |
| Dimensions (W × D × H) | 442.0 × 420.0 × 43.6 mm |
| Weight (device only) | ~ 5.8–6.0 kg (excluding optical/power/fan modules) |
| Power Supply Modules | Built-in dual AC power supplies (non-removable, simplified version) |
| Redundancy | Integrated redundancy (not pluggable PSU modules) |
| Power Consumption (Static) | ~ 60 W |
| Power Consumption (Typical) | ~ 80–90 W |
| Power Consumption (Maximum) | ~ 110 W |
| Heat Dissipation (Static) | ~ 205 BTU/hr |
| Heat Dissipation (Typical) | ~ 310 BTU/hr |
| Heat Dissipation (Maximum) | ~ 375 BTU/hr |
| Number of Fan Modules | 2–3 fixed fans (not hot-swappable, simplified design) |
| Airflow Direction Options | Fixed, port-side intake to power-side exhaust |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 132 Mpps |
| System Buffer | 16 MB |
| RTC | Supported |
| USB Deployment | Supported |
| Log Backup | Supported |
| Stacking | Supported (up to 9 devices with iStack) |
| Noise (at ~27 °C) | 42–47 dB(A) |
| Operating Conditions | Temp: 0–45 °C; Humidity: 5–95% (non-condensing); Altitude ≤ 5000 m |
| condition | new |
|---|
