Switch Huawei CloudEngine CE8855-32CQ4BQ
SKU
CE8855-32CQ4BQ
EAN:
21435
Condition:
new
Stock:
available on order
Lead time:
25-35 days
Huawei CloudEngine CE8855-32CQ4BQ 32 × 100GE QSFP28 + 4 × 400GE QSFP-DD (flexible breakout supported: 4 × 25GE, 2 × 50GE, or 4 × 100GE depending on optics)
Category: Huawei Switch
Switches Huawei CloudEngine 8800 series provide 32 ports 100Ge, 64 ports 40Ge or 128 ports 25/10GE In one body 2U, provide excellent bandwidth and low delay. Used as core level switches or aggregation in data centers and high -performance campus networks.
Switches CloudEngine series 8800 (CE8800) Supports interaction with switches CE5800/CE6800/CE7800/12800, which enables implementation of an elastic virtualized network that is easy to manage and meets the requirements of broadband, server data processing, and multimedia applications.
Specifications of the switch Huawei CE8855-32CQ4BQ:
| Specification | Detail |
|---|---|
| Product Name / Model | Huawei CloudEngine CE8855-32CQ4BQ |
| Type | Fixed Data Center Switch |
| Switching Capacity | 25.6 Tbps |
| Forwarding Performance | 8,000 Mpps |
| Ports | 32 × 100GE QSFP28 + 4 × 400GE QSFP-DD (flexible breakout supported: 4 × 25GE, 2 × 50GE, or 4 × 100GE depending on optics) |
| CPU | 16-core, 2.0 GHz |
| Memory | DRAM: 16 GB |
| Storage | Flash: 64 MB × 2; SSD: 240 GB |
| Buffer | 64 MB |
| Dimensions (H × W × D) | 43.6 mm × 442 mm × 600 mm |
| Weight | ~17 kg (with power modules and fan trays) |
| Power Supply | Pluggable AC / High-voltage DC modules, 1200 W each, 1+1 redundancy |
| Input Voltage | AC: 100 V – 240 V (50/60 Hz); HVDC: 190 V – 290 V |
| Power Consumption | Typical: ~820 W; Maximum: ~1,200 W |
| Airflow / Cooling | Front-to-back or back-to-front airflow (depending on fan trays); fan modules are hot-swappable |
| Operating Temperature | 0 °C to +45 °C (0–1800 m altitude) |
| Storage Temperature | –40 °C to +70 °C |
| Humidity | 5% – 95% (non-condensing) |
| Altitude | Up to 5,000 m (temperature derating above 1,800 m) |
| Noise Level | < 70 dB(A) at 27 °C |
| Reliability | Power modules: 1+1 redundancy; Fan modules: N+1 redundancy; All critical components hot-swappable |
| condition | new |
|---|
