Switch Huawei CloudEngine S1710I-S16D6A-LTECN
SKU
S1710I-S16D6A-LTECN
EAN:
21408
Condition:
new
Stock:
available on order
Lead time:
25-35 days
Huawei CloudEngine S1710I-S16D6A-LTECN 1 × FE electrical port, auto-sensing 10/100 Mbit/s
Category: Huawei Switch
Huawei CloudEngine S1730S – A series of highly effective switches used to create corporate networks. Switches easy to control they give the user equally good Internet connection, no matter their location.
The peculiarity of the series switches Huawei CloudEngine S1730S There is low noise and low power consumption, they belong to the class of energy -saving devices.
Specifications switch Huawei CloudEngine S1710I-S16D6A-LTECN:
| Specification | Detail |
|---|---|
| Product Name | Huawei CloudEngine S1710I-S16D6A-LTECN |
| Product Series | CloudEngine S1710I-S (Industrial Data Collection Gateway) |
| Memory | 512 KB |
| Flash | 66 MB |
| Fixed Ethernet Port | 1 × FE electrical port, auto-sensing 10/100 Mbit/s |
| Console Ports | 2 × RS-232 ports; 4 × RS-485 ports |
| Digital Inputs / Outputs (Alarm Ports) | 6 × DI (passive contact input, isolated); 2 × DI (passive contact input, non-isolated); 6 × DI relay outputs (normally open or closed) |
| Analog Input Ports | 2 × AI (0-5 V DC voltage input, and 4-20 mA current input) |
| SIM Card Slots | 2 × SIM cards (for LTE / cellular connectivity) |
| LTE Antenna Port | 1 LTE antenna port |
| BLE Antenna Port | 1 × BLE antenna port |
| Legacy / Other Interfaces | Includes FE, RS-232, RS-485, DI/DO, AI, etc. |
| Low Power Mode | Supported; meets battery endurance requirements (30 days) for hydrological data collection |
| Operating Environment / Durability | Designed for harsh IoT environments: wide temperature range (-40 °C to +70 °C), strong magnetic interference immunity, fanless design, meets relevant industrial/EM compatibility standards (IEC 61000-4 etc.) |
| Basic Network Protocols & Features | IPv4/IPv6, LTE & FE, TCP/UDP, ICMP, ARP, DHCP, DNS, NTP, MQTT, HTTP |
| Security & Reliability Features | SYN flood defense, PKI, communication encryption (HTTPS & MQTTS), application file encryption, key component management, configuration file backup & partition-based settings |
| Configuration & Management | Menu-based maintenance; user operation logs; system status monitoring; remote management via Huawei NCE-IoT; Bluetooth-based deployment possible |
| condition | new |
|---|
