Switch Huawei CloudEngine S1710I-S1FW
SKU
S1710I-S1FW
EAN:
21410
Condition:
new
Stock:
available on order
Lead time:
25-35 days
Huawei CloudEngine S1710I-S1FW 1 × FE electrical port (auto-sensing 10/100 Mbps)
Category: Huawei Switch
Huawei CloudEngine S1730S – A series of highly effective switches used to create corporate networks. Switches easy to control they give the user equally good Internet connection, no matter their location.
The peculiarity of the series switches Huawei CloudEngine S1730S There is low noise and low power consumption, they belong to the class of energy -saving devices.
Specifications of the switch Huawei CloudEngine S1710I-S1FW:
| Specification | Detail |
|---|---|
| Product Name / Model | Huawei CloudEngine S1710I-S1FW |
| Device Type | Industrial Data Collection Gateway / IoT Switch |
| Processor | ARM, single-core, 240 MHz |
| Memory (RAM) | 512 KB |
| Flash Storage | 66 MB |
| Fixed Ethernet Port | 1 × FE electrical port (auto-sensing 10/100 Mbps) |
| Console Ports | 2 × RS-232, 4 × RS-485 |
| Digital Input Ports (DI) | 6 × DI (passive contact input, isolated); 2 × DI (passive contact input, non-isolated) |
| Digital Output Ports (DO) | 6 × DO (relay outputs, normally open or closed) |
| Analog Input Ports (AI) | 2 × AI (0–5 V DC voltage input & 4–20 mA current input) |
| Console RJ45 Port | 1 × RJ45 |
| BLE Antenna Port | 1 × BLE antenna port |
| Wi-Fi Antenna Port | 1 × Wi-Fi antenna port |
| LTE Antenna Port | Not available |
| SIM Card Slots | Not available |
| Low-Power / Sleep Mode | Not supported |
| Operating Temperature Range | –40 °C to +70 °C |
| Storage Temperature Range | –40 °C to +85 °C |
| Operating Humidity | 5% to 95% RH, non-condensing |
| Enclosure / Design | Die-casting metal, fanless |
| Power Supply | DC input 9.6 V – 60 V |
| Power Consumption | < 3.7 W |
| Dimensions (HxWxD) | 55 × 150 × 133 mm |
| Net Weight | 0.82 kg |
| Installation Options | DIN-rail / Wall-mount / Bench-top |
| IP Rating | IP40 |
| EMC & Standards Compliance | IEC 61000-4, GB/T 17626, IEC 61850-3, EN 55032 / CISPR 32 Class A, Safety: IEC/EN/UL 60950-1, IEC/EN/UL 62368-1, GB 4943.1 |
| Supported Protocols | IPv4/IPv6, TCP/UDP, ICMP, ARP, DHCP, DNS, NTP, MQTT, HTTP |
| Security Features | SYN flood defense, PKI, HTTPS/MQTTS encryption, application file encryption, key management, partition-based configuration backup |
| Management & Configuration | Menu-based maintenance, user operation logs, system monitoring, remote management via Huawei NCE-IoT, Bluetooth-based deployment |
| condition | new |
|---|
