Switch Huawei CloudEngine S5731I-L8P2S2XN
Huawei CloudEngine S5731I‑L8P2S2XN 8 × 10/100/1000BASE‑T (RJ45)
Huawei S5700 – A series of highly effective, innovative switches consisting of a large number of devices and with different numbers 1G ports. Switches are equipped with interfaces uplink 10G and the enormous functionality of the software (Software).
Switches Huawei S5700 intended for use in places where excellent, high throughput, minimal latency, and fault tolerance are required.
Depending on the functionality of the software switches series Huawei S5700 separated into several series.
The switches are based Huawei — Versatile Routing Platform (VRP).
The peculiarity of this series of switches is: improved functionality 3-The level, Simplified operation and maintenance and flexible ways to organize the Internet.
Specifications of the switch Huawei CloudEngine S5731I-L8P2S2XN:
| Specification | Detail |
|---|---|
| Product Name / Model | Huawei CloudEngine S5731I‑L8P2S2XN |
| Series | S5731I‑L Series (DIN Rail‑Mounted Industrial Switch) |
| Downlink Ports | 8 × 10/100/1000BASE‑T (RJ45) |
| Uplink Ports | 2 × 100M/1G SFP ports; 2 × 1/10G SFP+ ports |
| Alarm / I/O Ports | 1 × DI (digital input); 1 × DO (digital output) |
| Switching Capacity | 98 Gbps |
| Forwarding Performance | 45 million packets per second (Mpps) |
| Power Supply | Dual DC input (12 V to 48 V DC) or external power module |
| PoE Support | Not supported |
| Operating Temperature Range | –40 °C to +75 °C |
| Storage Temperature Range | –40 °C to +85 °C |
| Relative Humidity | 5% to 95% (non‑condensing) |
| Heat Dissipation | Fanless, natural heat dissipation |
| Ingress Protection | IP40 |
| Dimensions (without packaging) | 150.0 mm × 44.0 mm × 133.0 mm |
| Weight (without packaging) | ~1.34 kg |
| Mounting | DIN rail |
| Surge Protection | Ports: ±6 kV common mode; Power input: ±2 kV differential mode & ±1 kV common mode |
| Compliance | IEC 61850‑3, IEEE 1613, EN 50121‑4, IEEE 802.3bt (PoE++) |
| condition | new |
|---|
