Switch Huawei CloudEngine S5735-S24P8J4XEZ-V2
CloudEngine S5735-S24P8J4XEZ-V2 24 × 10/100/1000BASE-T 8 × 2.5 GE SFP (optionally configurable as 2 × 10 GE SFP+) 4 × 10 GE SFP+ 2 × 12 GE stack ports
Huawei S5700 – A series of highly effective, innovative switches consisting of a large number of devices and with different numbers 1G ports. Switches are equipped with interfaces uplink 10G and the enormous functionality of the software (Software).
Switches Huawei S5700 intended for use in places where excellent, high throughput, minimal latency, and fault tolerance are required.
Depending on the functionality of the software switches series Huawei S5700 separated into several series.
The switches are based Huawei — Versatile Routing Platform (VRP).
The peculiarity of this series of switches is: improved functionality 3-The level, Simplified operation and maintenance and flexible ways to organize the Internet.
Specifications switch Huawei CloudEngine S5735-S24P8J4XEZ-V2:
| Feature | Specification |
|---|---|
| Model | CloudEngine S5735-S24P8J4XEZ-V2 |
| Form Factor | 1U Rack-mounted |
| Fixed Ports | 24 × 10/100/1000BASE-T8 × 2.5 GE SFP (optionally configurable as 2 × 10 GE SFP+)4 × 10 GE SFP+2 × 12 GE stack ports |
| Switching Capacity | 216 Gbps (device) / 520 Gbps (system) |
| Forwarding Performance | 162 Mpps |
| PoE Support | Yes, PoE+ (IEEE 802.3at) |
| Power Supply System | Up to 3 pluggable power modules, AC or DC input, 600 W or 1000 W, N+1 redundancy |
| Typical Power Consumption | Around 52.5 W |
| Maximum Power Consumption | Approximately 62 W |
| Expansion Slot | One rear expansion slot |
| MAC Address Table | Up to 32,000 entries |
| VLAN Support | Up to 4094 VLANs, Voice VLAN, MUX VLAN |
| Routing Features | Static routing, RIP, OSPF, BGP, VRRP, IS-IS, policy-based routing, ECMP |
| IPv6 Features | IPv6 routing, dual-stack, MLD snooping, ND, RA guard |
| Security Features | 802.1X authentication, MAC authentication, Portal authentication, ARP protection, DHCP snooping, IP Source Guard |
| Management Interfaces | Console port, USB port, Ethernet management port, MODE and PnP buttons |
| Redundancy & Reliability | N+1 power redundancy, device stacking (iStack), ERPS, Smart Link |
| Dimensions (H × W × D) | 43.6 × 442.0 × 420.0 mm |
| Weight | Approximately 5.0 kg |
| Operating Temperature | –5 °C to +50 °C |
| Operating Humidity | 5% to 95% non-condensing |
| Heat Dissipation | ~180 BTU/h (typical) |
| Acoustic Noise | Around 47 dB(A) sound power, 35 dB(A) sound pressure |
| MTBF (Mean Time Between Failures) | ~58 years |
| MTTR (Mean Time To Repair) | Approximately 2 hours |
| condition | new |
|---|
