Switch Huawei CloudEngine S5735-S24T8J4XE-XA-V2
CloudEngine S5735-S24T8J4XE-XA-V2 24 × 10/100/1000Base-T ports 8 × 2.5 GE SFP+ (can operate as 2 × 10 GE SFP+) 4 × 10 GE SFP+ ports 2 × 12 GE stack ports
Huawei S5700 – A series of highly effective, innovative switches consisting of a large number of devices and with different numbers 1G ports. Switches are equipped with interfaces uplink 10G and the enormous functionality of the software (Software).
Switches Huawei S5700 intended for use in places where excellent, high throughput, minimal latency, and fault tolerance are required.
Depending on the functionality of the software switches series Huawei S5700 separated into several series.
The switches are based Huawei — Versatile Routing Platform (VRP).
The peculiarity of this series of switches is: improved functionality 3-The level, Simplified operation and maintenance and flexible ways to organize the Internet.
Specifications switch Huawei CloudEngine S5735-S24T8J4XE-XA-V2:
| Feature | Specification |
|---|---|
| Model | CloudEngine S5735-S24T8J4XE-XA-V2 |
| Fixed Ports | 24 × 10/100/1000Base-T ports 8 × 2.5 GE SFP+ (can operate as 2 × 10 GE SFP+) 4 × 10 GE SFP+ ports 2 × 12 GE stack ports |
| Power Supply | Built-in dual AC power modules, 1+1 redundancy |
| Switching Capacity | 216 Gbps (device) / 520 Gbps (system) |
| Forwarding Performance | 162 Mpps |
| Layer 3 Features | Static routing, RIP/RIPng, OSPF/OSPFv3, IS-IS/IS-ISv6, BGP/BGP4+, VRRP/VRRP6, ECMP, policy-based routing |
| Multicast Support | IGMP snooping, PIM-SM, PIM-DM, PIM-SSM |
| Security Features | MAC authentication, 802.1X, DHCP snooping, ARP protection, IP Source Guard, DoS defense |
| Reliability Features | STP/RSTP/MSTP, ERPS (<50 ms protection), Smart Link |
| Stacking (iStack) | Supported; multiple units operate as one logical switch |
| O&M & Management | Zero-touch deployment, USB configuration, SNMP, CLI, Web, SSH, telemetry support |
| IPv6 Capabilities | Dual stack (IPv4/IPv6), RIPng, OSPFv3, IS-ISv6, IPv6 transition mechanisms |
| PoE | Not supported in this model |
| Dimensions (H × W × D) | 43.6 × 442.0 × 420.0 mm |
| Typical Use Cases | Campus access/aggregation layer, data center access layer |
| condition | new |
|---|
