Model
|
CloudEngine S5735-S8P2X-IA200H1
|
|
Fixed port
|
8 x 10/100/1000BASE-T PoE+ ports and 2 x 10GE SFP+ ports
|
|
Management port
|
Ethernet management port, console port (RJ45), and USB 2.0 port
|
|
PoE
|
• 8 PoE+ ports, each providing up to 30 W power
• 802.3af/802.3at standards compliance
• Maximum total PoE output power: 200 W
|
|
Dimensions (H x W x D)
|
570mm x 300mm×150mm
|
|
Net weight
|
14.5 kg
|
|
Mains input
|
|
Rated voltage range
|
220 V AC to 240 V AC, 50/60 Hz
|
|
Maximum voltage range
|
85 V AC to 290 V AC, 45 Hz to 66 Hz
|
|
Surge protection
|
Surge current:
• AC input: 20 kA in differential mode; 20 kA in common mode
Surge:
• AC input: ±6 kV in differential mode; ±6 kV in common mode
|
|
Solar power input
|
|
Solar input voltage
|
36 V to 120 V (typical value: 72 V)
|
|
Solar input power
|
0 W to 1400 W
|
|
Surge protection
|
Surge current:
• 3 kA in differential mode; 5 kA in common mode
Surge:
• ±2 kV in differential mode; ±4 kV in common mode
|
|
Input of stored energy
|
|
Type of stored energy
|
Lithium battery
|
|
Charging current
|
Maximum: 20 A
|
|
Charging voltage
|
43.2 V to 56.5 V
|
|
Input power
|
• 30–58 V: 500 W
• 58–72 V: 1400 W
• > 72 V: 1000 W
|
|
Surge protection
|
Surge current:
• 3 kA in differential mode; 5 kA in common mode
Surge:
• ±2 kV in differential mode; ±4 kV in common mode
|
|
Power output
|
|
Power output mode
|
• 12 V DC (two outputs)
• 24 V AC (two outputs)
• 220 V AC (standard configuration)
|
|
Output power
|
• Maximum total output power of 12 V DC + 24 V AC + PoE: 200 W
• 12 V DC (two outputs): 72 W in total, with a maximum of 72 W for a single output
• 24 V AC (two outputs): 100 W in total, with a maximum of 100 W for a single output
• Eight PoE ports: a maximum of 200 W output power
|
|
Surge protection
|
• 12 V DC output: ±2 kV in differential mode; ±4 kV in common mode
• 24 V AC output: ±2 kV in differential mode; ±6 kV in common mode
• Service port: ±1.5 kV in differential mode; ±6 kV in common mode
|
|
Maximum power consumption (100% throughput)
|
• No power output: 45 W
• 100% power output: 269 W (system power consumption: 69 W; power output: 200 W)
|
|
Typical power consumption (30% of traffic load, without PoE power output)
|
38 W
|
|
Fiber splice tray
|
Built-in (standard configuration)
|
|
Protection rating
|
IP55
|
|
Operating temperature
|
–40°C to +55°C
NOTE
–35ºC to +55ºC: sun shield needed; no requirement on the air velocity; GPON
optical modules supported
–35ºC to +45ºC: 1120 W/m2 solar radiation (maximum); no requirement on the air
velocity
–40ºC to –35ºC: At least four Ethernet electrical ports must be working.
When the altitude is 1800–4000 m, the highest operating temperature reduces by
1°C every time the altitude increases by 220 m.
|
|
Salt spray protection
|
Supported, allowing the switch to be installed in areas more than 500 meters away from the sea
|
|
Operating altitude
|
-150 m to +5000 m
|
|
Heat dissipation
|
Natural heat dissipation
|
|
Installation mode
|
Wall-mounted or pole-mounted
|
